OPTIONAL PARTS ACCESSORIES для Tohatsu M5B - 2013 года выпуска
-
№АртикулНазвание
-
1369-83880-2 Remote Control Fitting Ass'yRemote Control Fitting Ass'y
-
23A1-83722-0 * Ball Joint Holder* Ball Joint Holder
-
3332-83723-0 * Holder Cap* Holder Cap
-
4332-83724-0 * Spring* Spring
-
5332-83725-0 * Washer 5.5-14-1.2* Washer 5.5-14-1.2
-
6369-83820-0 * Cable Clip Ass'y* Cable Clip Ass'y
-
7910103-6616 * Bolt* Bolt
-
8930103-0600 * Nut* Nut
-
9369-83830-2 * Steering Hook Plate* Steering Hook Plate
-
10910103-0830 * Bolt* Bolt
-
11941303-0800 * Spring Washer* Spring Washer
-
12940103-0800 * Washer* Washer
-
13930103-0800 * Nut* Nut
-
14369-83726-0 * Throttle Lever* Throttle Lever
-
15369-67105-0 * Hook Lever Bushing* Hook Lever Bushing
-
16338-67147-0 * Seal Ring* Seal Ring
-
17941403-1400 * Wave Washer d=14* Wave Washer d=14
-
18369-83887-0 * Throttle Lever* Throttle Lever
-
19910103-6612 * Bolt* Bolt
-
20369-83888-0 * Collar 13.5-18-2.5* Collar 13.5-18-2.5
-
213C8-66308-0 * Washer 6-16-1.5* Washer 6-16-1.5
-
22369-83863-0 * Throttle Wire (Remote Control)* Throttle Wire (Remote Control)
-
23332-83728-0 * Pin* Pin
-
24332-83729-0 * Spring* Spring
-
25951403-0212 * Spring Pin 2-12* Spring Pin 2-12
-
26369-83715-1 * Cable Joint* Cable Joint
-
27369-83883-0 * Separate Cord
Brown* Separate Cord
Brown -
28369-83846-0 Remote Control Stop Cord L=2000Remote Control Stop Cord L=2000
-
28369-83848-0 Remote Control Stop Cord L=3200Remote Control Stop Cord L=3200
-
28369-83853-0 Remote Control Stop Cord L=3900Remote Control Stop Cord L=3900
-
28369-83858-0 Remote Control Stop Cord L=5900Remote Control Stop Cord L=5900
-
29345-66226-0 Grommet 17-3Grommet 17-3
-
1369-72100-0 Tool KitTool Kit
-
2312-72201-0 Safety Rope ?4-1000Safety Rope ?4-1000
-
3399-76101-0 Lighting KitLighting Kit
-
43H6-06128-0 * Alternator Kit
12V60W* Alternator Kit
12V60W -
5399-06023-1 ** Alternator Ass'y
12V60W** Alternator Ass'y
12V60W -
6921521-6520 ** Screw** Screw
-
7369-06915-0 ** Clamp 4.2-3-8** Clamp 4.2-3-8
-
8921521-6408 ** Screw** Screw
-
9369-76167-0 * Extension Cord (Light) L=2000* Extension Cord (Light) L=2000
-
10345-66226-0 * Grommet 17-3* Grommet 17-3
-
113H6-76160-0 * Rectifier Kit* Rectifier Kit
-
12369-76060-1 ** Rectifier Complete** Rectifier Complete
-
13334-76211-0 *** Fuse 10A*** Fuse 10A
-
14921503-0525 ** Screw** Screw
-
15940103-0500 ** Washer** Washer
-
16941303-0500 ** Spring Washer** Spring Washer
-
17930103-0500 ** Nut** Nut
-
18353-06972-0 ** Clamp 7-80P** Clamp 7-80P
-
19369-76161-0 ** Extension Cord** Extension Cord
-
20399B05180-0 Vertical Starter KitVertical Starter Kit
-
21369B05911-0 * Vertical Starter Guide* Vertical Starter Guide
-
22369-05913-0 * Tapping Screw* Tapping Screw
-
233B2-05912-0 * Seal* Seal
-
24369-64111-0 Test PropellerTest Propeller
-
25336-60007-0 Flushing PlugFlushing Plug
-
263B2Q63037-0 Long Handle L=400Long Handle L=400
-
263A1-63039-0 Long Handle L=800Long Handle L=800
-
263A1-63038-0 Long Handle L=1000Long Handle L=1000
-
273F3-72540-0 Spark Tester PET-4000Spark Tester PET-4000
-
28332-72306-0 Gear Oil 500mLGear Oil 500mL
-
293AC-72326-0 Touch-Up Paint
Aqua MarineTouch-Up Paint
Aqua Marine -
303C7-72301-0 Engine Oil 0.4LEngine Oil 0.4L
-
303C7-72302-0 Engine Oil 1LEngine Oil 1L
-
303C7-72304-0 Engine Oil 4LEngine Oil 4L
-
303C7-72303-0 Engine Oil 20LEngine Oil 20L
Все узлы модели:
- ASSEMBLY KIT PARTS
- BOTTOM COWL TILLER HANDLE
- BRACKET REVERSE LOCK ARM
- CARBURETOR
- CYLINDER CRANK CASE
- DRIVE SHAFT HOUSING SHIFT
- GEAR CASE
- INTEGRAL FUEL TANK (M5B-D, M5B, M4C)
- MAGNETO
- • OPTIONAL PARTS ACCESSORIES
- OPTIONAL PARTS REMOTE CONTROL
- RECOIL STARTER STARTER LOCK
- SEPARATE FUEL TANK DUAL FUEL (M5B-D, M5B-S)
- TOP COWL
