ASSEMBLY KIT PARTS для Tohatsu M4C - 2016 года выпуска

№

Артикул

Название
1

369Q87301-4 LOWER UNIT ASSY (S)
for Transom "S"

LOWER UNIT ASSY (S)
for Transom "S"

51 340 ₽
1

369Q87302-4 LOWER UNIT ASSY (L)
for Transom "L"

LOWER UNIT ASSY (L)
for Transom "L"

58 920 ₽
2

369Q87314-4 EXTENSION HOUSING KIT (UL)
for Transom "L"⇒"UL"

EXTENSION HOUSING KIT (UL)
for Transom "L"⇒"UL"

24 030 ₽
2

369Q61110-2 * EXTENSION HOUSING

* EXTENSION HOUSING

10 600 ₽
2

9161E3-0625 * BOLT

* BOLT

150 ₽
2

9401E3-0600 * WASHER

* WASHER

120 ₽
2

9401E3-0800 * WASHER

* WASHER

120 ₽
2

930103-0800 * NUT

* NUT

420 ₽
2

9152E3-0825 * STUD

* STUD

330 ₽
2

369-64303-0 * DRIVE SHAFT ASSY (UL)

* DRIVE SHAFT ASSY (UL)

10 980 ₽
2

369-65120-0 * WATER PIPE ASSY (UL)

* WATER PIPE ASSY (UL)

1 520 ₽
2

369-66014-2 * CAM ROD (UL)

* CAM ROD (UL)

2 050 ₽
3

3F9B87090-4 ENGINE SHORT BLOCK KIT
for M4C

ENGINE SHORT BLOCK KIT
for M4C

67 540 ₽
4

369-87122-1 CARBURETOR REPAIR KIT

CARBURETOR REPAIR KIT

8 450 ₽
4

369-02011-0 * CARBURETOR GASKET

* CARBURETOR GASKET

360 ₽
4

369-03222-0 * FLOAT CHAMBER O-RING

* FLOAT CHAMBER O-RING

1 310 ₽
4

369-03293-1 * GASKET

* GASKET

150 ₽
4

922503-6412 * SCREW

* SCREW

190 ₽
4

369-03231-0 * FLOAT

* FLOAT

3 350 ₽
4

346-03232-0 * FLOAT ARM PIN

* FLOAT ARM PIN

280 ₽
4

369-03240-0 * FLOAT VALVE

* FLOAT VALVE

1 890 ₽
4

344-03244-0 * CLIP

* CLIP

550 ₽
4

921521-0408 * SCREW

* SCREW

110 ₽
4

346-03256-0 * RUBBER CAP

* RUBBER CAP

570 ₽
4

369-03303-0 * DIAPHRAGM A

* DIAPHRAGM A

1 430 ₽
4

369-03306-0 * DIAPHRAGM B

* DIAPHRAGM B

1 450 ₽
4

922553-6423 * SCREW

* SCREW

420 ₽
4

369-03302-0 * PUMP COVER GASKET

* PUMP COVER GASKET

630 ₽
4

369-03307-0 * PUMP BODY GASKET

* PUMP BODY GASKET

690 ₽
4

369-03182-0 * CARBURETOR COVER GASKET

* CARBURETOR COVER GASKET

620 ₽
4

369-03183-0 * CARBURETOR COVER GASKET

* CARBURETOR COVER GASKET

570 ₽
4

369-03186-0 * SCREW

* SCREW

150 ₽
5

369-87121-5 POWER HEAD GASKET SET

POWER HEAD GASKET SET

10 820 ₽
5

369-01005-2 * CYLINDER HEAD GASKET

* CYLINDER HEAD GASKET

5 170 ₽
5

369-01215-0 * OIL SEAL 10.1-25-7
Crankcase Head

* OIL SEAL 10.1-25-7
Crankcase Head

1 100 ₽
5

369-01214-0 * CRANKCASE HEAD GASKET

* CRANKCASE HEAD GASKET

450 ₽
5

369-00122-0 * OIL SEAL 20-47-8
Crankshaft

* OIL SEAL 20-47-8
Crankshaft

1 430 ₽
5

369-03222-0 * FLOAT CHAMBER O-RING

* FLOAT CHAMBER O-RING

1 310 ₽
5

369-03293-1 * GASKET

* GASKET

150 ₽
5

369-02011-0 * CARBURETOR GASKET

* CARBURETOR GASKET

360 ₽
5

369-61012-2 * DRIVE SHAFT HOUSING GASKET

* DRIVE SHAFT HOUSING GASKET

1 490 ₽
6

369-87322-1 WATER PUMP REPAIR KIT

WATER PUMP REPAIR KIT

5 140 ₽
6

369-65018-0 * PUMP CASE GASKET

* PUMP CASE GASKET

250 ₽
6

369-65025-0 * WATER PUMP GUIDE PLATE

* WATER PUMP GUIDE PLATE

650 ₽
6

369-65029-0 * GUIDE PLATE GASKET

* GUIDE PLATE GASKET

540 ₽
6

369-65020-0 * PUMP CASE GASKET (LOWER)

* PUMP CASE GASKET (LOWER)

680 ₽
6

9161E3-0645 * BOLT

* BOLT

170 ₽
6

940103-0600 * WASHER

* WASHER

110 ₽
6

369-65022-0 * KEY ?2-11

* KEY ?2-11

270 ₽
6

369-65011-0 * PUMP CASE LINER

* PUMP CASE LINER

1 080 ₽
6

369-65021-1 * WATER PUMP IMPELLER

* WATER PUMP IMPELLER

2 660 ₽
7

369-65231-0 WATER PUMP KIT (CHROME PLATED)

WATER PUMP KIT (CHROME PLATED)

5 820 ₽
7

369-65021-1 * WATER PUMP IMPELLER

* WATER PUMP IMPELLER

2 660 ₽
7

369-65238-0 * PUMP CASE LINER
Chrome Plated

* PUMP CASE LINER
Chrome Plated

2 870 ₽
7

369-65239-0 * WATER PUMP GUIDE PLATE
Chrome Plated

* WATER PUMP GUIDE PLATE
Chrome Plated

2 180 ₽
7

369-65018-0 * PUMP CASE GASKET

* PUMP CASE GASKET

250 ₽
7

369-65029-0 * GUIDE PLATE GASKET

* GUIDE PLATE GASKET

540 ₽
8

369-87321-0 LOWER UNIT GASKET SET

LOWER UNIT GASKET SET

2 750 ₽
8

332-60006-0 * GASKET 8.1-15-1

* GASKET 8.1-15-1

200 ₽
8

369-60111-0 * OIL SEAL 15-28-10
Propeller Shaft

* OIL SEAL 15-28-10
Propeller Shaft

1 230 ₽
8

345-65015-0 * O-RING 3.2-47
Propeller Shaft Housing

* O-RING 3.2-47
Propeller Shaft Housing

360 ₽
8

369-65018-0 * PUMP CASE GASKET

* PUMP CASE GASKET

250 ₽
8

369-65029-0 * GUIDE PLATE GASKET

* GUIDE PLATE GASKET

540 ₽
8

369-60223-0 * OIL SEAL 10-24-8
Pump Case(Lower)

* OIL SEAL 10-24-8
Pump Case(Lower)

890 ₽
8

369-65020-0 * PUMP CASE GASKET (LOWER)

* PUMP CASE GASKET (LOWER)

680 ₽
8

369-66021-1 * O-RING 2.5-4.9
Cam Rod

* O-RING 2.5-4.9
Cam Rod

320 ₽
8

332-66032-0 * O-RING 2.4-15.4
Cam Rod Bushing

* O-RING 2.4-15.4
Cam Rod Bushing

320 ₽
