PISTON CRANK SHAFT для Tohatsu M4C - 2017 года выпуска
-
№АртикулНазвание
-
1369-00115-0 THRUST PLATETHRUST PLATE
-
2369-00122-0 OIL SEAL 20-47-8OIL SEAL 20-47-8
-
3350-00042-0 ROLLER BEARING 14-18-20
Small EndROLLER BEARING 14-18-20
Small End -
4369-00069-0 CRANKSHAFT SUB-ASSYCRANKSHAFT SUB-ASSY
-
5369-00031-0 * CRANKSHAFT A* CRANKSHAFT A
-
6369-00034-0 * CRANKSHAFT D* CRANKSHAFT D
-
7369-00061-1 * CRANK PIN* CRANK PIN
-
8369-00043-0 * ROLLER BEARING 20-26-12
Big End* ROLLER BEARING 20-26-12
Big End -
9369-00040-0 * CONNECTING ROD* CONNECTING ROD
-
109603-3-6204 BALL BEARING 6204BALL BEARING 6204
-
11338-00131-0 KEY
MagnetoKEY
Magneto -
12369-87130-0 PISTON REPAIR KIT
STDPISTON REPAIR KIT
STD -
12369-87131-0 PISTON REPAIR KIT (0.5 O/S)
OPTPISTON REPAIR KIT (0.5 O/S)
OPT -
13369-00001-1 * PISTON
STD* PISTON
STD -
13369-00004-1 * PISTON (0.5 O/S)
OPT* PISTON (0.5 O/S)
OPT -
14369-00021-1 * PISTON PIN* PISTON PIN
-
15350-00024-1 * PISTON PIN CLIP* PISTON PIN CLIP
-
16369-87123-0 PISTON RING SET
STDPISTON RING SET
STD -
16369-87124-0 PISTON RING SET (0.5 O/S)
OPTPISTON RING SET (0.5 O/S)
OPT -
17351-00011-0 * PISTON RING
STD* PISTON RING
STD -
17351-00014-0 * PISTON RING (0.5 O/S)
OPT* PISTON RING (0.5 O/S)
OPT
