OPTIONAL PARTS ACCESSORIES для Tohatsu M9.9D2 - 2017 года выпуска
-
№АртикулНазвание
-
13C8-72100-1 TOOL KITTOOL KIT
-
23B7-72201-0 SAFETY ROPE Ø5-1600SAFETY ROPE Ø5-1600
-
33B7-72530-2 TACHOMETER ASSYTACHOMETER ASSY
-
43B7-72659-0 * METER BULB 12V-1.7W* METER BULB 12V-1.7W
-
53B7-72656-0 * METER DAMPER* METER DAMPER
-
63B7-72661-0 * FITTING PLATE* FITTING PLATE
-
7930103-0500 * NUT* NUT
-
8941303-0500 * SPRING WASHER* SPRING WASHER
-
9361-72539-0 TACHOMETER LEAD WIRE L=6000TACHOMETER LEAD WIRE L=6000
-
103P0-72679-0 TACHOMETER UNIT KITTACHOMETER UNIT KIT
-
11345-67169-0 GROMMET 40-13-3GROMMET 40-13-3
-
12361-72542-0 SEPARATE CORD
WhiteSEPARATE CORD
White -
12361-72543-0 SEPARATE CORD
YellowSEPARATE CORD
Yellow -
13336-60007-0 FLUSHING PLUGFLUSHING PLUG
-
14346-76160-2 RECTIFIER KITRECTIFIER KIT
-
15361-76161-0 * EXTENSION CORD* EXTENSION CORD
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INTAKE MAINFOLD
- CARBURETOR
- RECOIL STARTER
- MAGNETO ELECTRIC PARTS
- DRIVE SHAFT HOUSING
- GEAR CASE
- BRACKET
- TILLER HANDLE
- BOTTOM COWL
- SHIFT
- REMOTE CONTROL PARTS
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- • OPTIONAL PARTS ACCESSORIES
- ASSEMBLY KIT PARTS
