DRIVE SHAFT HOUSING GEAR CASE(M2,5/3,5A2) для Tohatsu M2.5A2 - 2019 года выпуска
-
№АртикулНазвание
-
1309Q60000-2 GEAR CASE ASSYGEAR CASE ASSY
-
2309-64321-1 * SPACER* SPACER
-
39601-0-6001 * BALL BEARING 6001
Drive Shaft* BALL BEARING 6001
Drive Shaft -
4945002-2800 * C-RING d=28* C-RING d=28
-
5309-64311-1 DRIVE SHAFT (LOWER)DRIVE SHAFT (LOWER)
-
69601-0-6300 BALL BEARING 6300
Bevel GearBALL BEARING 6300
Bevel Gear -
7309-64017-0 SHIM 17.5-10.2-0.05SHIM 17.5-10.2-0.05
-
7309-64015-0 SHIM 17.5-10.2-0.1SHIM 17.5-10.2-0.1
-
7309-64014-0 SHIM 17.5-10.2-0.2SHIM 17.5-10.2-0.2
-
8309-64020-0 BEVEL GEAR BBEVEL GEAR B
-
9945307-0700 E-RING d=7E-RING d=7
-
10309-65021-1 WATER PUMP IMPELLERWATER PUMP IMPELLER
-
11309-65022-0 KEY φ4-15KEY φ4-15
-
12309Q65010-1 WATER PUMP CASEWATER PUMP CASE
-
139601-0-6001 BALL BEARING 6001
Propeller ShaftBALL BEARING 6001
Propeller Shaft -
14309-60111-0 OIL SEAL 12-24-8OIL SEAL 12-24-8
-
15309-65015-0 O-RING 1.5-47.75O-RING 1.5-47.75
-
16309-65032-0 GROMMET 10.2-8GROMMET 10.2-8
-
17309-64210-0 PROPELLER SHAFT ASSY
Bevel Gear APROPELLER SHAFT ASSY
Bevel Gear A -
189101E3-7630 BOLTBOLT
-
19309-60223-0 OIL SEAL 13-28.1-18OIL SEAL 13-28.1-18
-
20309Q60101-1 WATER PUMP CASE COVERWATER PUMP CASE COVER
-
21309Q61020-2 DRIVE SHAFT HOUSING (S)
for Transom "S"DRIVE SHAFT HOUSING (S)
for Transom "S" -
21309Q61030-2 DRIVE SHAFT HOUSING (L)
for Transom "L"DRIVE SHAFT HOUSING (L)
for Transom "L" -
22309-64312-1 DRIVE SHAFT (UPPER S)
for Transom "S"DRIVE SHAFT (UPPER S)
for Transom "S" -
22309-64313-1 DRIVE SHAFT (UPPER L)
for Transom "L"DRIVE SHAFT (UPPER L)
for Transom "L" -
23309-64322-0 GIRD PIPE
for Transom "S"GIRD PIPE
for Transom "S" -
23309-64323-0 GIRD PIPE
for Transom "L"GIRD PIPE
for Transom "L" -
24309-65100-0 WATER PIPE ASSY (S)
for Transom "S"WATER PIPE ASSY (S)
for Transom "S" -
24309-65110-0 WATER PIPE ASSY (L)
for Transom "L"WATER PIPE ASSY (L)
for Transom "L" -
25309Q67521-0 CARRYING HANDLECARRYING HANDLE
