PISTON CRANK SHIFT для Tohatsu M8B - 2019 года выпуска

№

Артикул

Название
1

3B2-00069-0 CRANKSHAFT SUB-ASSY

CRANKSHAFT SUB-ASSY

48 110 ₽
2

3B2-00040-0 * CONNECTING ROD

* CONNECTING ROD

4 970 ₽
3

3B2-00043-0 * ROLLER BEARING 17-23-14
Big End

* ROLLER BEARING 17-23-14
Big End

2 360 ₽
4

3B2-00031-0 * CRANKSHAFT A

* CRANKSHAFT A

11 850 ₽
5

3B2-00032-0 * CRANKSHAFT B

* CRANKSHAFT B

10 900 ₽
6

3B2-00033-0 * CRANKSHAFT C

* CRANKSHAFT C

10 600 ₽
7

3B2-00034-0 * CRANKSHAFT D

* CRANKSHAFT D

10 110 ₽
8

3B2-00061-2 * CRANK PIN

* CRANK PIN

990 ₽
9

350-00062-0 * SEALING PLUG
Crankshaft D

* SEALING PLUG
Crankshaft D

220 ₽
10

3B2-00051-0 * OIL SEAL 25-47-7

* OIL SEAL 25-47-7

1 320 ₽
11

369-00115-0 * THRUST PLATE

* THRUST PLATE

200 ₽
12

9603-3-6204 * BALL BEARING 6204
Center

* BALL BEARING 6204
Center

2 890 ₽
13

9603-3-6204 BALL BEARING 6204
Upper, Lower

BALL BEARING 6204
Upper, Lower

2 890 ₽
14

338-00042-0 ROLLER BEARING 14-18-19
Small End

ROLLER BEARING 14-18-19
Small End

1 800 ₽
15

101-00121-0 OIL SEAL 20-35-7

OIL SEAL 20-35-7

370 ₽
16

3B2-87130-0 PISTON REPAIR KIT
STD

PISTON REPAIR KIT
STD

4 360 ₽
16

3B2-87131-0 PISTON REPAIR KIT (0.5 O/S)
OPT

PISTON REPAIR KIT (0.5 O/S)
OPT

4 720 ₽
17

3B2-00001-1 * PISTON
STD

* PISTON
STD

6 610 ₽
17

3B2-00004-1 * PISTON (0.5 O/S)
OPT

* PISTON (0.5 O/S)
OPT

7 050 ₽
18

3B2-00021-1 * PISTON PIN

* PISTON PIN

1 520 ₽
19

350-00024-1 * PISTON PIN CLIP

* PISTON PIN CLIP

320 ₽
20

3G0-87123-0 PISTON RING SET
STD

PISTON RING SET
STD

1 610 ₽
20

3G0-87124-0 PISTON RING SET (0.5 O/S)
OPT

PISTON RING SET (0.5 O/S)
OPT

2 120 ₽
21

3B2-00011-0 * PISTON RING
STD

* PISTON RING
STD

1 500 ₽
21

3B2-00014-0 * PISTON RING (0.5 O/S)
OPT

* PISTON RING (0.5 O/S)
OPT

2 150 ₽
