REMOTE CONTROL для Tohatsu M8B - 2020 года выпуска
-
№АртикулНазвание
-
33B2-83880-3 REMOTE CONTROL FITTING ASSY
OPTREMOTE CONTROL FITTING ASSY
OPT -
43A1-83722-0 * BALL JOINT HOLDER* BALL JOINT HOLDER
-
5332-83723-0 * HOLDER CAP* HOLDER CAP
-
6332-83724-0 * SPRING* SPRING
-
7332-83725-0 * WASHER 5.5-14-1.2* WASHER 5.5-14-1.2
-
83B2-83820-0 * CABLE CLIP ASSY* CABLE CLIP ASSY
-
9910103-6616 * BOLT* BOLT
-
10930103-0600 * NUT* NUT
-
11369-83830-2 * STEERING HOOK PLATE* STEERING HOOK PLATE
-
12910103-5830 * BOLT* BOLT
-
13930103-0800 * NUT* NUT
-
14941303-0800 * SPRING WASHER* SPRING WASHER
-
15940103-0800 * WASHER* WASHER
-
16369-83726-0 * THROTTLE LEVER* THROTTLE LEVER
-
17369-67105-0 * HOOK LEVER BUSHING* HOOK LEVER BUSHING
-
18338-67147-0 * SEAL RING 13.8-22-3.7* SEAL RING 13.8-22-3.7
-
19941403-1400 * WAVE WASHER d=14* WAVE WASHER d=14
-
203B2-83887-1 * THROTTLE LEVER* THROTTLE LEVER
-
21910103-6612 * BOLT* BOLT
-
223C8-66308-0 * WASHER 6-16-1.5* WASHER 6-16-1.5
-
233B2-83863-1 * THROTTLE LEVER ROD* THROTTLE LEVER ROD
-
243B2-83865-0 * NUT 10-32UNF* NUT 10-32UNF
-
25345-05224-0 * ROD SNAP 5-2.5* ROD SNAP 5-2.5
-
263A1-83710-1 * CABLE JOINT ASSY* CABLE JOINT ASSY
-
303B2-83857-0 REMOTE CONTROL STOP CORD ASSY L=3900
OPTREMOTE CONTROL STOP CORD ASSY L=3900
OPT -
303K9-83857-0 REMOTE CONTROL STOP CORD ASSY L=5900
OPTREMOTE CONTROL STOP CORD ASSY L=5900
OPT -
31345-66226-0 * GROMMET 17-3* GROMMET 17-3
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHIFT
- INTAKE MAINFOLD REED VALVE THROTTLE
- CARBURETOR FUEL PUMP
- RECOIL STARTER STARTER LOCK
- MAGNETO ELECTRIC PARTS
- DRIVE SHAFT HOUSING
- GEAR CASE
- BRACKET REVERSE LOCK
- TILLER HANDLE (MF EF MODEL)
- BOTTOM COWL
- SHIFT
- • REMOTE CONTROL
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- OPTIONAL PARTS (ACCESSORIES)
- ASSEMBLY KIT PARTS
