BRAKE - REAR CALIPER для Yamaha RAPTOR 250 - 2008 года выпуска
-
№АртикулНазвание
-
15YT-25712-00-00 BRACKET, DISCBRACKET, DISC
-
24D3-2582W-00-00 DISC, REAR BRAKE 2DISC, REAR BRAKE 2
-
390109-081F0-00 BOLTBOLT
-
490170-33010-00 NUTNUT
-
590113-06055-00 BOLT, SETBOLT, SET
-
690208-34001-00 WASHER, CONICAL SPRINGWASHER, CONICAL SPRING
-
75YT-2580W-10-00 CALIPER ASSY, REAR 2CALIPER ASSY, REAR 2
-
85LP-W0057-50-00 ...PISTON ASSY, CALIPER...PISTON ASSY, CALIPER
-
95LP-W0047-50-00 ...CALIPER SEAL KIT...CALIPER SEAL KIT
-
101UY-25972-51-00 ...ADJUSTBOLT...ADJUSTBOLT
-
114D3-W0046-50-00 ...BRAKE PAD KIT 2...BRAKE PAD KIT 2
-
121UY-W0048-50-00 ...BLEED SCREW KIT...BLEED SCREW KIT
-
131UY-25924-51-00 ...PIN, PAD...PIN, PAD
-
141UY-25917-51-00 ...BOOT, CALIPER...BOOT, CALIPER
-
155YT-25977-50-00 ...SPRING, RETURN...SPRING, RETURN
-
161UY-25933-51-00 ...LOCK WASHER - BRAKE...LOCK WASHER - BRAKE
-
1790105-08183-00 BOLT, FLANGEBOLT, FLANGE
