WHEEL - FRONT W/ AXLE ASSY для Yamaha WOLVERINE 350 2WD - 2008 года выпуска
-
№АртикулНазвание
-
15ND-F5180-11-00 RIM FRONT (BLACK)RIM FRONT (BLACK)
-
294108-12808-00 TIRE (AT23X8-12) CHENG SHINTIRE (AT23X8-12) CHENG SHIN
-
393900-00813-00 VALVE, RIMVALVE, RIM
-
490179-10022-00 NUTNUT
-
55GT-2512A-00-00 CAP, WHEELCAP, WHEEL
-
65HA-25181-00-00 AXLE, WHEELAXLE, WHEEL
-
75ND-F3501-10-00 STEERING KNUCKLE ASSY (LEFT)STEERING KNUCKLE ASSY (LEFT)
-
893306-006Y2-00 ...BEARING...BEARING
-
993106-38046-00 ...OIL SEAL...OIL SEAL
-
1093106-38047-00 ...OIL SEAL...OIL SEAL
-
1190560-30325-00 ...SPACER...SPACER
-
125FU-F3549-00-00 ...BALL JOINT 1...BALL JOINT 1
-
1393410-32075-00 ...CIRCLIP, S-TYPE...CIRCLIP, S-TYPE
-
145ND-F5111-20-00 HUB, FRONTHUB, FRONT
-
1590114-10014-00 BOLT, SERRATIONBOLT, SERRATION
-
1693210-27666-00 O-RINGO-RING
-
1790201-168R1-00 WASHER, PLATEWASHER, PLATE
-
1890171-16002-00 NUT, CASTLENUT, CASTLE
-
1991402-30030-00 PIN, COTTERPIN, COTTER
-
205ND-F5180-11-00 RIM FRONT (BLACK)RIM FRONT (BLACK)
-
2194108-12808-00 TIRE (AT23X8-12) CHENG SHINTIRE (AT23X8-12) CHENG SHIN
-
2293900-00813-00 VALVE, RIM (TR413)VALVE, RIM (TR413)
-
2390179-10022-00 NUTNUT
-
245GT-2512A-00-00 CAP, WHEELCAP, WHEEL
-
255ND-F3502-10-00 STEERING KNUCKLE ASSY (RIGHT)STEERING KNUCKLE ASSY (RIGHT)
-
2693306-006Y2-00 ...BEARING...BEARING
-
2793106-38046-00 ...OIL SEAL...OIL SEAL
-
2893106-38047-00 ...OIL SEAL...OIL SEAL
-
2990560-30325-00 ...SPACER...SPACER
-
305FU-F3549-00-00 ...BALL JOINT 1...BALL JOINT 1
-
3193410-32075-00 ...CIRCLIP, S-TYPE...CIRCLIP, S-TYPE
-
325ND-F5111-20-00 HUB, FRONTHUB, FRONT
-
3390114-10014-00 BOLT, SERRATIONBOLT, SERRATION
-
3493210-27666-00 O-RINGO-RING
-
3590201-168R1-00 WASHER, PLATEWASHER, PLATE
-
3690171-16002-00 NUT, CASTLENUT, CASTLE
-
3791402-30030-00 PIN, COTTERPIN, COTTER
-
385ND-F514A-00-00 RING, WHEEL 1RING, WHEEL 1
-
3995822-06012-00 BOLT, FLANGEBOLT, FLANGE
