ELECTRICAL для Yamaha GRIZZLY 350 - 2009 года выпуска
-
№АртикулНазвание
-
15UH-85540-00-00 C.D.I. UNIT ASSYC.D.I. UNIT ASSY
-
297702-60420-00 SCREW, TAPPINGSCREW, TAPPING
-
390462-06016-00 CLAMPCLAMP
-
490338-08226-00 PLUG, SPEC'L SHAPEPLUG, SPEC'L SHAPE
-
53GB-82540-01-00 NEUTRAL SWITCH ASSYNEUTRAL SWITCH ASSY
-
690430-10148-00 GASKETGASKET
-
75KM-82310-00-00 IGNITION COIL ASSYIGNITION COIL ASSY
-
890109-06865-00 BOLTBOLT
-
95UH-H1318-00-00 SPACERSPACER
-
1097002-06020-00 BOLTBOLT
-
1192902-06600-00 WASHER, PLATEWASHER, PLATE
-
121UY-82370-20-00 PLUG CAP ASSYPLUG CAP ASSY
-
134GB-83591-10-00 THERMO UNITTHERMO UNIT
-
1490201-12172-00 WASHER, PLATEWASHER, PLATE
-
155GT-81960-00-00 RECTIFIER AND REGULATOR ASSYRECTIFIER AND REGULATOR ASSY
-
1695802-06020-00 BOLT, FLANGEBOLT, FLANGE
-
175TE-H2100-00-00 BATTERY ASSY (YUASA YTX14AH)BATTERY ASSY (YUASA YTX14AH)
-
185TE-H2128-01-00 BRACKET, BATTERYBRACKET, BATTERY
-
19371-82121-00-00 PAD, BATTERYPAD, BATTERY
-
205ND-H2119-00-00 COVER, LEAD WIRECOVER, LEAD WIRE
-
2195802-06020-00 BOLT, FLANGEBOLT, FLANGE
-
2297702-60016-00 SCREW, TAPPINGSCREW, TAPPING
-
235TE-H2115-00-00 WIRE, PLUS LEADWIRE, PLUS LEAD
-
245UH-H2116-00-00 WIRE, MINUS LEADWIRE, MINUS LEAD
-
255TE-83530-00-00 PILOT LIGHT ASSYPILOT LIGHT ASSY
-
265GH-83516-00-00 BULB (14V-1.7W)BULB (14V-1.7W)
-
274KB-83530-30-00 PILOT LIGHT ASSY RED OILPILOT LIGHT ASSY RED OIL
-
285GH-83516-00-00 BULB (14V-1.7W)BULB (14V-1.7W)
-
2990338-14827-00 PLUG, SPEC'L SHAPEPLUG, SPEC'L SHAPE
-
3090338-14827-00 PLUG, SPEC'L SHAPEPLUG, SPEC'L SHAPE
-
314SV-81940-12-00 STARTER RELAY ASSYSTARTER RELAY ASSY
-
321AE-82151-00-00 FUSE (30 AMP, BLADE)FUSE (30 AMP, BLADE)
-
3395022-06008-00 BOLT, FLANGEBOLT, FLANGE
-
3490464-10833-00 CLAMPCLAMP
-
355LP-82510-00-00 MAIN SWITCH ASSYMAIN SWITCH ASSY
-
355KM-82510-00-00 MAIN SWITCH ASSY APMAIN SWITCH ASSY AP
-
363HN-82569-00-00 NUT, MAIN SWITCHNUT, MAIN SWITCH
-
373HN-82579-00-00 CAP, KEYCAP, KEY
-
384KB-82530-10-00 STOP SWITCH ASSYSTOP SWITCH ASSY
-
395WH-82590-20-00 WIRE HARNESS ASSYWIRE HARNESS ASSY
-
395WH-82590-40-00 WIRE HARNESS ASSY APWIRE HARNESS ASSY AP
-
403D5-82180-00-00 CIRCUIT BREAKER ASSYCIRCUIT BREAKER ASSY
-
413D5-82560-00-00 THERMO SWITCH ASSYTHERMO SWITCH ASSY
-
425JJ-82151-10-00 FUSE (15A-BL)FUSE (15A-BL)
-
435JJ-82151-30-00 FUSE (10A-BL)FUSE (10A-BL)
-
443WP-81980-00-00 DIODE ASSYDIODE ASSY
-
4529U-81950-93-00 RELAY ASSYRELAY ASSY
-
465DM-81950-00-00 RELAY ASSY (G8HN-1C4T-DJ-Y52)RELAY ASSY (G8HN-1C4T-DJ-Y52)
-
4790464-51800-00 CLAMPCLAMP
-
4890464-12830-00 CLAMPCLAMP
-
4990464-40825-00 CLAMPCLAMP
-
5090464-31827-00 CLAMPCLAMP
-
5190464-40825-00 CLAMPCLAMP
-
5290464-25800-00 CLAMPCLAMP
-
5390464-25800-00 CLAMPCLAMP
-
5490464-16006-00 CLAMPCLAMP
-
5590464-25800-00 CLAMPCLAMP
-
5690464-40825-00 CLAMPCLAMP
-
5790464-48800-00 CLAMPCLAMP
-
5890464-48800-00 CLAMPCLAMP
-
5990464-25800-00 CLAMPCLAMP
-
6090464-12830-00 CLAMPCLAMP
-
6190464-31827-00 CLAMPCLAMP
-
6290464-31827-00 CLAMPCLAMP
-
6390464-12830-00 CLAMPCLAMP
-
6490464-48800-00 CLAMPCLAMP
-
6590464-12830-00 CLAMPCLAMP
-
6690464-48800-00 CLAMPCLAMP
-
675FU-H1920-10-00 TERMINAL ASSYTERMINAL ASSY
-
685FU-H191B-10-01 NUTNUT
-
695FU-H2599-01-01 COVER, CONNECTERCOVER, CONNECTER
-
7090890-56001-00 KEY BLANK (A-TYPE)KEY BLANK (A-TYPE)
-
7190890-56002-00 KEY BLANK (B-TYPE)KEY BLANK (B-TYPE)
