FENDER - REAR для Yamaha YFZ450R - 2018 года выпуска
-
№АртикулНазвание
-
11TD-F1600-00-00 REAR FENDER ASSYREAR FENDER ASSY
-
218P-21643-00-00 STAY, FENDER 3STAY, FENDER 3
-
392012-08016-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
418P-21644-00-00 STAY, FENDER 4STAY, FENDER 4
-
592012-08016-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
64XV-2177L-01-00 PLATE, SPRINGPLATE, SPRING
-
78HG-28386-00-00 HEADHEAD
-
81TD-21652-00-00 PROTECTORPROTECTOR
-
918P-2163E-00-00 COVER, 2COVER, 2
-
101TD-2163F-00-00 COVER, REAR FENDER 3COVER, REAR FENDER 3
-
111TD-F1621-00-00 FLAPFLAP
-
121TD-2164F-00-00 STAY 1STAY 1
-
131TD-2164H-00-00 STAY 3STAY 3
-
1490154-05043-00 SCREW, BINDINGSCREW, BINDING
-
1592012-06030-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
1690387-06205-00 COLLARCOLLAR
-
1795602-06200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
1890201-06076-00 WASHER, PLATEWASHER, PLATE
-
191TD-F1691-00-00 FLAPFLAP
-
201TD-2164G-00-00 STAY 2STAY 2
-
211TD-2164J-00-00 STAY 4STAY 4
-
2290154-05043-00 SCREW, BINDINGSCREW, BINDING
-
2392012-06030-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
2490387-06205-00 COLLARCOLLAR
-
2595602-06200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
2690201-06076-00 WASHER, PLATEWASHER, PLATE
-
2795822-08025-00 BOLT, FLANGEBOLT, FLANGE
-
2890201-08048-00 WASHER, PLATEWASHER, PLATE
-
2995602-08200-00 NUT, U FLANGENUT, U FLANGE
-
3092012-08020-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
3190201-08043-00 WASHER, PLATEWASHER, PLATE
-
3218P-2163A-00-00 COVER, REAR FENDER 1COVER, REAR FENDER 1
-
3390109-06249-00 BOLTBOLT
