WHEEL - REAR для Yamaha V STAR 1100 MIDNIGHT CUSTOM - 2006 года выпуска
-
№АртикулНазвание
-
15EL-25311-00-00 HUB, REARHUB, REAR
-
290387-173M5-00 COLLARCOLLAR
-
393306-20348-00 BEARINGBEARING
-
493306-30317-00 BEARINGBEARING
-
593102-25044-00 OIL SEAL, SD-TYPEOIL SEAL, SD-TYPE
-
616G-25366-01-00 CLUTCH, HUBCLUTCH, HUB
-
75EL-25364-00-00 DAMPERDAMPER
-
893210-48530-00 O-RINGO-RING
-
993210-59531-00 O-RINGO-RING
-
1016G-25412-00-00 WASHERWASHER
-
1190170-10219-00 NUTNUT
-
1293210-57428-00 O-RINGO-RING
-
135KS-25304-00-00 SPOKE SET, REARSPOKE SET, REAR
-
1494445-15607-00 RIM (MT4.50-15M/C)RIM (MT4.50-15M/C)
-
153HT-25398-00-00 BALANCER, WHEEL (15G)BALANCER, WHEEL (15G)
-
1694117-1508W-00 TIRE (170/80-15 M/C 77S K555) (DUNLOP)TIRE (170/80-15 M/C 77S K555) (DUNLOP)
-
1694117-15008-00 TIRE (170/80-15 M/C 77S G546) (BRIDGESTONE)TIRE (170/80-15 M/C 77S G546) (BRIDGESTONE)
-
1794217-15298-00 TUBE (170/80-15 M/C PV78) (BRIDGESTONE)TUBE (170/80-15 M/C PV78) (BRIDGESTONE)
-
1794217-15299-00 TUBE (170/80-15 M/C PV78) (DUNLOP)TUBE (170/80-15 M/C PV78) (DUNLOP)
-
1894317-15180-00 BAND, RIM (4.50-15) (DUNLOP)BAND, RIM (4.50-15) (DUNLOP)
-
1894317-15181-00 BAND, RIM (4.50-15) (BRIDGESTONE)BAND, RIM (4.50-15) (BRIDGESTONE)
-
195EL-25381-00-00 AXLE, WHEELAXLE, WHEEL
-
2090201-160T2-00 WASHER, PLATEWASHER, PLATE
-
2195604-16200-00 NUT, U FLANGENUT, U FLANGE
-
2290387-177Y4-00 COLLARCOLLAR
-
234H7-25377-00-00 COLLAR, WHEELCOLLAR, WHEEL
