BRAKE - REAR MASTER CYLINDER для Yamaha V STAR 1300 - 2008 года выпуска
-
№АртикулНазвание
-
13D8-2583V-00-00 RR. MASTER CYLINDER ASSY.RR. MASTER CYLINDER ASSY.
-
25EL-W0042-50-00 ...CYLINDER KIT, MASTER...CYLINDER KIT, MASTER
-
32VN-25866-00-00 ...CIRCLIP...CIRCLIP
-
493210-15620-00 ...O-RING...O-RING
-
52VN-2582A-50-00 ...JOINT...JOINT
-
695024-08035-00 BOLT, FLANGE (3EF)BOLT, FLANGE (3EF)
-
75EL-25867-01-00 BRACKET, MASTER CYLINDERBRACKET, MASTER CYLINDER
-
892014-08016-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
95EL-27491-00-00 PROTECTORPROTECTOR
-
1090401-10020-00 BOLT, UNIONBOLT, UNION
-
1190430-10005-00 GASKETGASKET
-
123D8-2581J-00-00 HOSE, BRAKE 4HOSE, BRAKE 4
-
1390464-15192-00 CLAMPCLAMP
-
143D8-21374-00-00 HOLDER, FUEL PIPEHOLDER, FUEL PIPE
-
1590464-12036-00 CLAMPCLAMP
