SUSPENSION - FRONT FORK для Yamaha V STAR 650 CLASSIC [ XVS65AZR/L/CR/CL] (1BF1/1BF2) - 2010 года выпуска
-
№АртикулНазвание
-
15BN-23102-12-00 FRONT FORK ASSY (LEFT)FRONT FORK ASSY (LEFT)
-
25BN-23126-11-00 TUBE, OUTER (LEFT)TUBE, OUTER (LEFT)
-
35BN-23193-00-00 GUIDE, BOOTGUIDE, BOOT
-
45BN-23110-01-00 INNER TUBE COMP.1INNER TUBE COMP.1
-
55BN-23171-00-00 PISTON, FRONT FORKPISTON, FRONT FORK
-
65BN-23170-00-00 CYLINDER COMP., FRONT FORKCYLINDER COMP., FRONT FORK
-
74FM-23125-40-00 METAL, SLIDE 1METAL, SLIDE 1
-
836Y-23146-10-00 WASHER, OIL SEALWASHER, OIL SEAL
-
94EB-23145-01-00 OIL SEALOIL SEAL
-
1026H-23156-00-00 RING, SNAPRING, SNAP
-
114EB-23144-00-00 SEAL, DUSTSEAL, DUST
-
124YR-23173-00-00 SPINDLE, TAPERSPINDLE, TAPER
-
13509-23158-L0-00 GASKETGASKET
-
14278-23181-50-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
155BN-23141-00-00 SPRING, FRONT FORKSPRING, FRONT FORK
-
164DW-23149-40-00 WASHER, SPRING UPPERWASHER, SPRING UPPER
-
174TR-23118-00-00 SPACERSPACER
-
181D0-23111-00-00 BOLT, CAPBOLT, CAP
-
1943F-23188-10-00 O-RINGO-RING
-
205BN-23103-12-00 FRONT FORK ASSY (RIGHT)FRONT FORK ASSY (RIGHT)
-
215BN-23136-11-00 TUBE, OUTER (RIGHT)TUBE, OUTER (RIGHT)
-
225BN-23193-00-00 GUIDE, BOOTGUIDE, BOOT
-
235BN-23110-01-00 INNER TUBE COMP.1INNER TUBE COMP.1
-
245BN-23171-00-00 PISTON, FRONT FORKPISTON, FRONT FORK
-
255BN-23170-00-00 CYLINDER COMP., FRONT FORKCYLINDER COMP., FRONT FORK
-
264FM-23125-40-00 METAL, SLIDE 1METAL, SLIDE 1
-
2736Y-23146-10-00 WASHER, OIL SEALWASHER, OIL SEAL
-
284EB-23145-01-00 OIL SEALOIL SEAL
-
2926H-23156-00-00 RING, SNAPRING, SNAP
-
304EB-23144-00-00 SEAL, DUSTSEAL, DUST
-
314YR-23173-00-00 SPINDLE, TAPERSPINDLE, TAPER
-
32509-23158-L0-00 GASKETGASKET
-
33278-23181-50-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
345BN-23141-00-00 SPRING, FRONT FORKSPRING, FRONT FORK
-
354DW-23149-40-00 WASHER, SPRING UPPERWASHER, SPRING UPPER
-
364TR-23118-00-00 SPACERSPACER
-
371D0-23111-00-00 BOLT, CAPBOLT, CAP
-
3843F-23188-10-00 O-RINGO-RING
-
3991314-08040-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
405KS-23340-10-00 UNDER BRACKET COMP.UNDER BRACKET COMP.
-
4191314-08020-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
425BN-23123-10-00 COVER, UNDER 1COVER, UNDER 1
-
435BN-23133-10-00 COVER, LOWER 2COVER, LOWER 2
-
445KS-23121-20-00 COVER, UPPER 1COVER, UPPER 1
-
455KS-23131-20-00 COVER, UPPER 2COVER, UPPER 2
-
465BN-23163-00-00 GASKETGASKET
-
475BN-23394-01-00 BOLT, SPECIALBOLT, SPECIAL
-
485KS-23165-10-00 WASHER, FELTWASHER, FELT
-
494KM-23123-01-00 COVER, UNDER 1COVER, UNDER 1
-
5093399-99932-00 BEARINGBEARING
-
513FV-23462-00-00 SEAL, STEERINGSEAL, STEERING
