SADDLEBAGS для Yamaha V STAR 1300 DELUXE - 2015 года выпуска
-
№АртикулНазвание
-
12CA-F841L-P1-00 BODY 1 - VIVID RED - LEFTBODY 1 - VIVID RED - LEFT
-
22CA-F844B-P1-00 LID.1 - VIVID RED - LEFT, INCL. SEAL, 1LID.1 - VIVID RED - LEFT, INCL. SEAL, 1
-
35S6-F8444-V0-00 HINGE 1 (LEFT) CHROMEHINGE 1 (LEFT) CHROME
-
42CA-F845L-V0-00 OPEN, STOPPER 1OPEN, STOPPER 1
-
52C5-F849K-V0-00 STOPPER, SADDLEBAGSTOPPER, SADDLEBAG
-
690111-05812-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
72C5-F841F-00-00 PLATEPLATE
-
82C5-F848U-00-00 COLLAR 1COLLAR 1
-
95S6-F8487-00-00 PLATE, 2PLATE, 2
-
102C5-F8487-00-00 PLATE, 2PLATE, 2
-
112C5-F849K-V0-00 STOPPER, SADDLEBAGSTOPPER, SADDLEBAG
-
122C5-F848T-00-00 ...PLATE, LOCK 1...PLATE, LOCK 1
-
1390111-05X05-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
142CA-F8467-V0-00 SPACERSPACER
-
159011-05813-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
1690201-05802-00 WASHER, PLAINWASHER, PLAIN
-
175S6-28428-00-00 SEAL 1SEAL 1
-
185S6-28408-00-00 LOCK ASSY 1LOCK ASSY 1
-
192CA-F841M-P1-00 BODY 2 - VIVID RED RIGHT NOT SHOWNBODY 2 - VIVID RED RIGHT NOT SHOWN
-
202CA-F844C-P1-00 LID 2 - VIVID RED - RIGHT NOT SHOWN, INCL. SEALLID 2 - VIVID RED - RIGHT NOT SHOWN, INCL. SEAL
-
215S6-F845E-T0-00 HINGE 1, RIGHT NOT SHOWNHINGE 1, RIGHT NOT SHOWN
-
222C5-F8493-V0-00 COVER LOCK ASSY 1, RIGHT NOT SHOWNCOVER LOCK ASSY 1, RIGHT NOT SHOWN
-
232CA-F8428-V0-00 SEAL, 1 RIGHT & LEFTSEAL, 1 RIGHT & LEFT
