FUEL TANK для Yamaha XL 800 Z - 2001 года выпуска
-
№АртикулНазвание
-
1EW2-62140-00-00 FILTER, VENT ASSYFILTER, VENT ASSY
-
2EW2-62142-00-00 PLATE, FILTERPLATE, FILTER
-
370R-24543-00-00 ...PLUG, DRAIN...PLUG, DRAIN
-
470R-24489-00-00 ...O-RING...O-RING
-
590267-489U2-00 ...RIVET, BLIND (YMUS)...RIVET, BLIND (YMUS)
-
6F0D-U785G-00-00 HOSE, AIR VENT (YMUS)HOSE, AIR VENT (YMUS)
-
790465-11829-00 CLAMP (YMUS)CLAMP (YMUS)
-
890465-11829-00 CLAMP (YMUS)CLAMP (YMUS)
-
990464-99801-00 CLAMP (YMUS)CLAMP (YMUS)
-
10F0D-U7711-00-00 TANK, FUEL (YMUS)TANK, FUEL (YMUS)
-
11GP7-U7831-00-00 CAP, FUEL FILLER (PURE WHITE)CAP, FUEL FILLER (PURE WHITE)
-
12GP7-U7832-00-00 PACKING (YMUS)PACKING (YMUS)
-
13GP7-U7833-00-00 SOCKET (YMUS)SOCKET (YMUS)
-
14GP7-U7835-00-00 CHAIN BALL (YMUS)CHAIN BALL (YMUS)
-
1590169-049U1-00 TAPPING SCREW (YMUS)TAPPING SCREW (YMUS)
-
16GP7-U7834-00-00 PACKING FUEL FILLER (YMUS)PACKING FUEL FILLER (YMUS)
-
1790267-329UR-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
18GP7-U783F-00-00 NUT, FUEL FILLER (YMUS)NUT, FUEL FILLER (YMUS)
-
19F0D-U7844-00-00 HOSE (YMUS)HOSE (YMUS)
-
2090601-155U4-00 BAND, HOSE 5 (YMUS)BAND, HOSE 5 (YMUS)
-
21EU0-67767-31-00 CHECK VALVECHECK VALVE
-
22GP7-U785H-00-00 HOSE, AIR VENT 3 (YMUS)HOSE, AIR VENT 3 (YMUS)
-
2390465-11829-00 CLAMP (YMUS)CLAMP (YMUS)
-
24F0D-U7856-00-00 HOSE, AIR VENT 3 (YMUS)HOSE, AIR VENT 3 (YMUS)
-
25GH3-67743-01-00 BELT, TANK 1BELT, TANK 1
-
2690119-089U7-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
27F0D-U759B-00-00 MAT 1 (YMUS)MAT 1 (YMUS)
-
28F0D-U759B-10-00 MAT 1 (YMUS)MAT 1 (YMUS)
-
29F0D-U759C-00-00 MAT 2 (YMUS)MAT 2 (YMUS)
-
30GJ1-U759C-00-00 MAT 2 (YMUS)MAT 2 (YMUS)
