CONSOLE ASSY для Yamaha VENTURE 700 - 2001 года выпуска
-
№АртикулНазвание
-
18CR-77711-01-00 PANEL, INSTRUMENT (VT600F)PANEL, INSTRUMENT (VT600F)
-
18DM-77711-00-00 PANEL, INSTRUMENT (VT700F)PANEL, INSTRUMENT (VT700F)
-
28CR-77741-10-00 INDICATOR 1 (VT600F)INDICATOR 1 (VT600F)
-
28DM-77741-00-00 INDICATOR 1 (VT700F)INDICATOR 1 (VT700F)
-
38CW-77742-00-00 INDICATOR 2 (VT600F)INDICATOR 2 (VT600F)
-
38DM-77742-00-00 INDICATOR 2 (VT700F)INDICATOR 2 (VT700F)
-
498907-06012-00 SCREW, BINDSCREW, BIND
-
590387-0611K-00 COLLARCOLLAR
-
68M6-77175-00-00 HOLDER, LATCHHOLDER, LATCH
-
790154-06077-00 SCREW, BINDINGSCREW, BINDING
-
890387-064W3-00 COLLARCOLLAR
-
990201-06071-00 WASHER, PLATEWASHER, PLATE
-
108CR-2196T-00-00 TRIM 1TRIM 1
