CONSOLE ASSY для Yamaha SRVIPER S TX 137 DX - 2017 года выпуска
-
№АртикулНазвание
-
18JP-K7712-00-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
28JM-RA201-00-00 SCREW, TAPPING 10-12X5/8SCREW, TAPPING 10-12X5/8
-
38JP-K7131-00-00 LOUVER 1LOUVER 1
-
48JP-RA253-00-00 SCREW, M6-1.0X18SCREW, M6-1.0X18
-
58JP-RA373-00-00 NUT, INSERTNUT, INSERT
-
68LJ-K7222-00-00 BRACKET, WINDSHIELD (RIGHT HAND)BRACKET, WINDSHIELD (RIGHT HAND)
-
78LJ-K7222-10-00 BRACKET, WINDSHIELD (LEFT HAND)BRACKET, WINDSHIELD (LEFT HAND)
-
88JP-RA363-00-00 NUT, FLANGE LOCKING M5X0.8NUT, FLANGE LOCKING M5X0.8
-
98JP-RA280-00-00 SCREW, TAPPING M6X12SCREW, TAPPING M6X12
-
108LJ-RA239-00-00 SCREW, 5SCREW, 5
-
118JY-K7711-20-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
128JP-RA252-00-00 SCREW, M6-1.0X15SCREW, M6-1.0X15
-
138JP-H2627-00-00 SWITCHSWITCH
-
148JP-K6169-00-00 NUTNUT
-
158JP-RA352-00-00 .NUT, CLIP 10.NUT, CLIP 10
-
168JR-K7713-00-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
178JP-K7761-70-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
188JP-K7761-S0-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
198JP-K7561-00-00 ...PROTECTOR, SIDE 1...PROTECTOR, SIDE 1
-
208JP-R4261-00-00 ...VELCRO (6.5 FEET)...VELCRO (6.5 FEET)
-
218JP-RA345-00-00 NUT, 1NUT, 1
-
228JP-RAK02-00-00 PIN, 2PIN, 2
