EXHAUST SYSTEM для Yamaha SRX 120 - 2017 года выпуска
-
№АртикулНазвание
-
18JM-F1912-00-00 PANEL, SUB FRAME 1PANEL, SUB FRAME 1
-
28JM-RA600-00-00 ...PLUG, 1...PLUG, 1
-
38JM-RA501-00-00 RIVET, BLIND 2RIVET, BLIND 2
-
48JM-F199H-00-00 SHIELD, HEATSHIELD, HEAT
-
58JP-RA533-00-00 RIVET, 21RIVET, 21
-
68JM-E4750-00-00 SILENCER ASSYSILENCER ASSY
-
78JP-RA514-00-00 RIVET, 5RIVET, 5
-
88JM-RAD04-00-00 SPRING, TENSION 3SPRING, TENSION 3
-
98JM-E4718-00-00 PROTECTOR, MUFFLER 1PROTECTOR, MUFFLER 1
-
108JM-F194J-00-00 STAY, MUFFLERSTAY, MUFFLER
-
118KC-RA290-00-00 SCREWSCREW
-
128JM-RA503-00-00 RIVET, BLIND 4RIVET, BLIND 4
-
138JM-F198G-00-00 COVER 2COVER 2
-
148JM-F198F-00-00 COVER 1COVER 1
Все узлы модели:
- AIR SHROUD W/ RECOIL STARTER
- CAMSHAFT W/ VALVE
- CARBURETOR ASSY
- CRANKCASE ASSY
- CRANKSHAFT W/ PISTON ASSY
- CYLINDER W/ HEAD ASSY
- DRIVE TRAIN ASSEMBLY
- ELECTRICAL - MAGNETO ASSEMBLY
- • EXHAUST SYSTEM
- FRONT FRAME COMP. 1
- GOVERNOR
- HANDLEBAR ASSY W/ STEERING ASSY
- HEAD & TAIL LIGHT
- HOOD - WINDSHIELD ASSY
- INTAKE W/ AIR BOX ASSY - FUEL PUMP
- MODEL INFO - MANUALS
- SEAT ASSY
- SUSPENSION - FRONT W/ SKI ASSY
- SUSPENSION - IDLER WHEELS W/ RAIL ASSY - TRACK
- SUSPENSION - IDLER WHEELS W/ RAIL ASSY - TRACK 2
- TUNNEL EXTENSION ASSEMBLY
