SHIFT SHAFT для Yamaha RHINO 660 - 2007 года выпуска
-
№АртикулНазвание
-
15UG-13487-00-00 GUIDE, OIL HOSEGUIDE, OIL HOSE
-
24SH-18198-00-00 LEVERLEVER
-
390387-0613B-00 COLLARCOLLAR
-
490201-132G5-00 WASHER, PLATEWASHER, PLATE
-
590508-35764-00 SPRING, TORSIONSPRING, TORSION
-
690201-06008-00 WASHER, PLATEWASHER, PLATE
-
795817-06035-00 BOLT, FLANGEBOLT, FLANGE
-
85KM-18191-00-00 LEVERLEVER
-
95KM-18197-00-00 SHAFTSHAFT
-
1093102-15212-00 OIL SEAL, SD-TYPEOIL SEAL, SD-TYPE
-
115UG-18104-00-00 SHIFT GUIDE COMP.SHIFT GUIDE COMP.
-
125KM-18129-01-00 COVER, SHIFT SHAFTCOVER, SHIFT SHAFT
-
135KM-18146-00-00 GASKETGASKET
-
1495027-06020-00 BOLT, FLANGEBOLT, FLANGE
-
1595027-06030-00 BOLT, FLANGEBOLT, FLANGE
-
1699530-08012-00 PIN, DOWELPIN, DOWEL
-
1790201-06008-00 WASHER, PLATEWASHER, PLATE
-
185UG-18115-00-00 ROD, SHIFTROD, SHIFT
-
1990170-08358-00 NUTNUT
-
2095307-08700-00 NUTNUT
-
215UG-18300-01-00 SHIFTER ASSYSHIFTER ASSY
-
225UG-18174-00-00 ...KNOB, SHIFT LEVER...KNOB, SHIFT LEVER
-
2390269-05055-00 ...RIVET, SPEC'L SHAPE...RIVET, SPEC'L SHAPE
-
245GH-18131-00-00 ...BOOT, SEALING...BOOT, SEALING
-
255GH-18617-00-00 ...STOPPER, RUBBER...STOPPER, RUBBER
-
2695817-06016-00 BOLT, FLANGEBOLT, FLANGE
-
2795807-08012-00 BOLT, FLANGEBOLT, FLANGE
-
284GY-1443E-00-00 PIPE, DRAINPIPE, DRAIN
-
2990467-15012-00 CLIPCLIP
