HANDLEBAR ASSEMBLY для Arctic Cat DVX 400 (BLACK/CAT GREEN) [A2008DVI2AUSE] - 2008 года выпуска
-
№АртикулНазвание
-
13405-024 HANDLEBARHANDLEBAR
-
23405-040 COVER, STEERING HEADCOVER, STEERING HEAD
-
33423-735 CLIP (BLACK)CLIP (BLACK)
-
43405-032 BRACKET, MOUNTING - RIGHTBRACKET, MOUNTING - RIGHT
-
53405-033 BRACKET, MOUNTING - LEFTBRACKET, MOUNTING - LEFT
-
63405-026 BALANCER SET, HANDLEBAR (INC. 7-12)BALANCER SET, HANDLEBAR (INC. 7-12)
-
73423-660 ...SCREW...SCREW
-
83405-029 ...EXPANDER...EXPANDER
-
93423-672 ...WASHER (6.5X14X2)...WASHER (6.5X14X2)
-
103405-030 ...EXPANDER...EXPANDER
-
113405-031 ...SPACER...SPACER
-
123423-668 ...NUT...NUT
-
133487-005 CABLE, CLUTCHCABLE, CLUTCH
-
143487-006 CABLE, THROTTLECABLE, THROTTLE
-
153445-038 CABLE, STARTER PLUNGERCABLE, STARTER PLUNGER
-
163423-714 WASHERWASHER
-
173406-113 GUIDE, CABLEGUIDE, CABLE
-
183423-627 BOLTBOLT
-
193487-004 CABLE, PARKING BRAKECABLE, PARKING BRAKE
-
203406-114 GUIDE, PARKING BRAKE CABLEGUIDE, PARKING BRAKE CABLE
-
213423-730 CLAMPCLAMP
-
223406-115 STOPPER, CABLESTOPPER, CABLE
-
233423-780 CLAMPCLAMP
-
243423-729 CLAMPCLAMP
-
253008-044 CLAMP, CABLECLAMP, CABLE
