STARTER MOTOR AND OIL PUMP ASSEMBLY для Arctic Cat 150 YOUTH RED [A2010KYC2BUSR] - 2010 года выпуска
-
№АртикулНазвание
-
13304-999 PUMP, OIL - ASSEMBLY (INC. 2-3)PUMP, OIL - ASSEMBLY (INC. 2-3)
-
23304-426 ...SCREW, MACHINE...SCREW, MACHINE
-
33304-144 ...PIN, DOWEL...PIN, DOWEL
-
43303-385 SCREW, CAPSCREW, CAP
-
53303-046 SPROCKETSPROCKET
-
63303-331 NUTNUT
-
73305-002 CHAIN, OIL PUMPCHAIN, OIL PUMP
-
83305-003 COVER, CHAINCOVER, CHAIN
-
93303-381 SCREW, CAPSCREW, CAP
-
103305-012 CABLE, STARTER (INC. 11)CABLE, STARTER (INC. 11)
-
113305-252 ...BOOT, TERMINAL...BOOT, TERMINAL
-
123305-011 MOTOR, STARTER (INC. 13)MOTOR, STARTER (INC. 13)
-
133304-104 ...O-RING 24.4*3.1...O-RING 24.4*3.1
-
143305-019 SCREW, MACHINESCREW, MACHINE
-
153303-382 SCREW, CAPSCREW, CAP
-
163305-005 SHAFT, REDUCTION GEARSHAFT, REDUCTION GEAR
-
173305-004 GEAR, REDUCTIONGEAR, REDUCTION
-
183305-009 PLATE, CLUTCHPLATE, CLUTCH
-
193305-008 SPRING ROLLER STARTER CLUTCHSPRING ROLLER STARTER CLUTCH
-
203305-010 ROLLER, STARTERROLLER, STARTER
-
213305-015 ROLLER 10*10ROLLER 10*10
-
223303-395 PIN, SPRINGPIN, SPRING
-
233305-020 SCREW, CAPSCREW, CAP
-
243305-007 CLUTCH, OUTERCLUTCH, OUTER
-
253305-006 GEAR, STARTERGEAR, STARTER
-
263305-671 BEARING NEEDLE 28*32*17/0.002~0.004BEARING NEEDLE 28*32*17/0.002~0.004
-
273305-014 WASHER, THRUST 22.2*39*2.5WASHER, THRUST 22.2*39*2.5
-
283305-013 NUTNUT
