STEERING ASSEMBLY для Arctic Cat 300 2X4 [A2013KUF2BUSP] - 2013 года выпуска
-
№АртикулНазвание
-
13303-957 POST, STEERINGPOST, STEERING
-
23305-496 BUSHINGBUSHING
-
33305-927 BLOCK, MOUNTING - STEERING POSTBLOCK, MOUNTING - STEERING POST
-
43304-649 SCREW, CAPSCREW, CAP
-
53303-962 CLAMP, MOUNTING BLOCKCLAMP, MOUNTING BLOCK
-
63304-130 NUT, CASTLENUT, CASTLE
-
73304-136 WASHERWASHER
-
83303-960 COLLAR, STEERING POST - LOWERCOLLAR, STEERING POST - LOWER
-
93304-032 NUT, LOCKNUT, LOCK
-
103303-470 PIN, COTTERPIN, COTTER
-
113304-143 PIN, COTTERPIN, COTTER
-
123303-969 TIE ROD - ASSEMBLY (INC. 13-17)TIE ROD - ASSEMBLY (INC. 13-17)
-
133303-971 ...END, TIE ROD - RIGHT-HAND THREAD...END, TIE ROD - RIGHT-HAND THREAD
-
143303-326 ...NUT - RIGHT-HAND THREAD...NUT - RIGHT-HAND THREAD
-
153304-376 ...TIE ROD...TIE ROD
-
163303-327 ...NUT - LEFT-HAND THREAD...NUT - LEFT-HAND THREAD
-
173303-973 ...END, TIE ROD - LEFT-HAND THREAD...END, TIE ROD - LEFT-HAND THREAD
