SECONDARY TRANSMISSION ASSEMBLY для Arctic Cat Prowler 700 HDX 4x4 - STEEL BLUE [U2013P5T1PUSV] - 2013 года выпуска
-
№АртикулНазвание
-
10822-144 COUNTERSHAFT ASSEMBLY (INC. 2-10)COUNTERSHAFT ASSEMBLY (INC. 2-10)
-
20831-085 ...RING, RETAINING...RING, RETAINING
-
30822-120 ...GEAR SELECT, REVERSE...GEAR SELECT, REVERSE
-
40822-121 ...SHIM...SHIM
-
50822-119 ...GEAR, REVERSE DRIVEN...GEAR, REVERSE DRIVEN
-
60832-082 ...BEARING...BEARING
-
70822-114 ...GEAR, DRIVEN - LOW...GEAR, DRIVEN - LOW
-
80822-113 ...COUNTERSHAFT...COUNTERSHAFT
-
90822-145 ...GEAR SELECT, SLIDING...GEAR SELECT, SLIDING
-
100822-148 ...GEAR, DRIVEN-HIGH, (30T - UC)...GEAR, DRIVEN-HIGH, (30T - UC)
-
110822-125 GEAR,SPUR - 13T-13T 20° PAGEAR,SPUR - 13T-13T 20° PA
-
120828-019 WASHER, THRUSTWASHER, THRUST
-
130828-011 WASHERWASHER
-
140831-040 RING, RETAININGRING, RETAINING
-
150822-050 TRIGGER, SPEEDOMETER SENSORTRIGGER, SPEEDOMETER SENSOR
-
160828-069 WASHER, THRUSTWASHER, THRUST
-
170831-039 RING, RETAININGRING, RETAINING
-
180830-129 GASKETGASKET
-
190829-023 PIN, DOWELPIN, DOWEL
-
200822-049 HOUSING, SPEEDOMETER SENSORHOUSING, SPEEDOMETER SENSOR
-
210430-091 SENSOR, SPEEDOMETERSENSOR, SPEEDOMETER
-
228468-620 SCREW, MACH-TSPNH M6X1.0X20 CL8.8 BLACKSCREW, MACH-TSPNH M6X1.0X20 CL8.8 BLACK
-
238468-645 SCREW, MACH-TSPNH M6X1.0X45 CL8.8 BLACKSCREW, MACH-TSPNH M6X1.0X45 CL8.8 BLACK
-
240830-107 GASKETGASKET
-
250822-001 DRIVESHAFTDRIVESHAFT
-
260828-016 WASHER, THRUSTWASHER, THRUST
-
270822-011 GEAR, REVERSE IDLEGEAR, REVERSE IDLE
-
280822-012 BUSHINGBUSHING
-
290822-015 SHAFT, REVERSE IDLESHAFT, REVERSE IDLE
