WHEEL AND TIRE ASSEMBLY для Arctic Cat 1000 MUD PRO LTD BLACK [A2015MLW1PUSJ] - 2015 года выпуска
-
№АртикулНазвание
-
10423-557 SCREW, SHOULDERSCREW, SHOULDER
-
21436-418 DISC, BRAKE 10 INCHDISC, BRAKE 10 INCH
-
31502-437 HUB - ASSEMBLY (INC. 4)HUB - ASSEMBLY (INC. 4)
-
40402-974 ...STUD...STUD
-
50423-607 NUT, CASTLENUT, CASTLE
-
60423-407 PIN, COTTERPIN, COTTER
-
72402-155 WHEEL - FRONTWHEEL - FRONT
-
80503-860 RING, BEADLOCK - BLACKRING, BEADLOCK - BLACK
-
91423-259 WASHERWASHER
-
101423-258 SCREW, CAP - BLACKSCREW, CAP - BLACK
-
112402-194 CAP, WHEELCAP, WHEEL
-
120402-064 STEM, VALVE - W/CAPSTEM, VALVE - W/CAP
-
130423-618 NUT, LUG - CHROMENUT, LUG - CHROME
-
141402-855 TIRE - FRONTTIRE - FRONT
-
152402-156 WHEEL - REARWHEEL - REAR
-
161402-901 TIRE - REAR 28X11-14TIRE - REAR 28X11-14
