REAR AXLE AND BRAKE ASSEMBLY для Arctic Cat 90 2X4 DVX GREEN [A2015KSB2BUSZ] - 2015 года выпуска
-
№АртикулНазвание
-
13304-565 BOLT, FLANGE - 8 X 20BOLT, FLANGE - 8 X 20
-
23303-607 WASHER, SPRING - 8 MMWASHER, SPRING - 8 MM
-
33305-835 RETAINER, SPROCKETRETAINER, SPROCKET
-
43305-298 O-RINGO-RING
-
53303-148 SPROCKET, FINAL DRIVESPROCKET, FINAL DRIVE
-
63305-840 RING, RETAININGRING, RETAINING
-
73305-838 AXLE, REARAXLE, REAR
-
83305-347 HUB, REAR - ASSEMBLY (INC. 9-11)HUB, REAR - ASSEMBLY (INC. 9-11)
-
93303-461 ...SEAL...SEAL
-
103303-466 ...BEARING...BEARING
-
113303-427 ...SPACER...SPACER
-
123303-281 WASHERWASHER
-
133303-379 SCREW, CAPSCREW, CAP
-
143303-147 ADJUSTER, CHAIN - ASSEMBLY (INC. 15-17)ADJUSTER, CHAIN - ASSEMBLY (INC. 15-17)
-
153304-135 ...WASHER, PLAIN - 8 MM...WASHER, PLAIN - 8 MM
-
163303-607 ...WASHER, SPRING - 8 MM...WASHER, SPRING - 8 MM
-
173304-125 ...NUT...NUT
-
183303-162 DISC, BRAKEDISC, BRAKE
-
193303-253 BOLT, DISKBOLT, DISK
-
203305-249 BRACKET, BRAKE DISCBRACKET, BRAKE DISC
-
213305-839 NUTNUT
-
223307-089 CALIPER, REAR - ASSEMBLY (INC. 23-33)CALIPER, REAR - ASSEMBLY (INC. 23-33)
-
233304-331 ...CAP, BLEED VALVE...CAP, BLEED VALVE
-
243307-091 ...VALVE, BLEED...VALVE, BLEED
-
253304-334 ...PLUG...PLUG
-
263305-380 ...SEAL, PISTON (FOOT BRAKE)...SEAL, PISTON (FOOT BRAKE)
-
273307-092 ...PISTON...PISTON
-
283304-589 ...BOOT...BOOT
-
293304-590 ...BOOT B...BOOT B
-
303304-315 ...SPRING...SPRING
-
313306-585 ...SEAL, DUST...SEAL, DUST
-
323307-090 ...BRACKET...BRACKET
-
333303-908 ...PAD, BRAKE - SET...PAD, BRAKE - SET
-
343303-256 SCREW, CAPSCREW, CAP
-
353303-144 GUARD, CHAINGUARD, CHAIN
-
363304-610 SCREW, CAPSCREW, CAP
