CLUTCH ASSEMBLY для Arctic Cat WILDCAT X LTD WHITE [U2015WTW1POSC] (INTERNATIONAL) - 2015 года выпуска
-
№АртикулНазвание
-
10823-498 CLUTCH, PRIMARY IDLER - 7.25 IN. - ASSEMBLY (INC. 2-11)CLUTCH, PRIMARY IDLER - 7.25 IN. - ASSEMBLY (INC. 2-11)
-
20823-499 ...CLUTCH, DRIVE - UNCALIBRATED (INC. 3-5)...CLUTCH, DRIVE - UNCALIBRATED (INC. 3-5)
-
30623-914 ......SCREW, SELF-TAPPING......SCREW, SELF-TAPPING
-
40823-424 ......COVER, SHEAVE......COVER, SHEAVE
-
50823-402 ......SCREW, CAP......SCREW, CAP
-
60823-426 ...KIT, CAM ARM (INC. 7-9)...KIT, CAM ARM (INC. 7-9)
-
70823-399 ......NUT, LOCK......NUT, LOCK
-
80823-396 ......PIN, CAM ARM......PIN, CAM ARM
-
90823-397 ......WASHER, THRUST......WASHER, THRUST
-
100823-429 ...WEIGHT, CLUTCH-69G...WEIGHT, CLUTCH-69G
-
110823-500 ...SPRING, DRIVE CLUTCH BLK/SILVER...SPRING, DRIVE CLUTCH BLK/SILVER
-
121623-649 WASHER, HIGH COLLARWASHER, HIGH COLLAR
-
130826-159 BOLT, CLUTCHBOLT, CLUTCH
-
140823-496 BELT, DRIVEBELT, DRIVE
-
150826-158 SCREW, CAPSCREW, CAP
-
160828-133 WASHERWASHER
-
170828-137 SHIM, 12 X 24 X 0.25 MMSHIM, 12 X 24 X 0.25 MM
-
170828-134 SHIM, 12 X 24 X 0.50 MMSHIM, 12 X 24 X 0.50 MM
-
180823-461 CLUTCH, SECONDARY - ASSEMBLY (8.91") (INC. 19-36)CLUTCH, SECONDARY - ASSEMBLY (8.91") (INC. 19-36)
-
190823-404 ...RING, RETAINING...RING, RETAINING
-
200823-405 ...WASHER, THRUST...WASHER, THRUST
-
210823-406 ...SHIM, 38 X 62 X 1.50 MM...SHIM, 38 X 62 X 1.50 MM
-
220823-459 ...SHEAVE, STATIONARY...SHEAVE, STATIONARY
-
230823-460 ...SHEAVE, MOVABLE...SHEAVE, MOVABLE
-
240823-410 ...PIN, ROLLER...PIN, ROLLER
-
250823-409 ...WASHER, THRUST...WASHER, THRUST
-
260823-462 ...ROLLER...ROLLER
-
270823-407 ...PIN, SPRING...PIN, SPRING
-
280823-411 ...SPRING...SPRING
-
290823-412 ...BEARING ASSEMBLY...BEARING ASSEMBLY
-
300823-413 ...INSERT, SPIDER...INSERT, SPIDER
-
310823-414 ...SPIDER...SPIDER
-
320823-417 ...ROLLER...ROLLER
-
330823-416 ...WASHER, THRUST...WASHER, THRUST
-
340823-415 ...E-RING...E-RING
-
350823-418 ...CAM, DRIVEN...CAM, DRIVEN
-
360823-419 ...SCREW, MACHINE...SCREW, MACHINE
