REAR SUSPENSION ASSEMBLY для Arctic Cat XR 500 RED [A2015XAK4USR] - 2015 года выпуска
-
№АртикулНазвание
-
10404-419 SHOCK ABSORBERSHOCK ABSORBER
-
20403-395 CAM, ADJUSTER - SPRINGCAM, ADJUSTER - SPRING
-
30504-883 SPRING, SUSPENSION - WHITESPRING, SUSPENSION - WHITE
-
41603-889 RETAINER, SPRINGRETAINER, SPRING
-
58409-045 SCREW, CAPSCREW, CAP
-
60423-744 NUT, LOCKNUT, LOCK
-
70504-948 A-ARM, REAR - UPPER - BLACK (INC. 8-9)A-ARM, REAR - UPPER - BLACK (INC. 8-9)
-
80403-289 ...BUSHING, UPPER A-ARM SUSPENSION...BUSHING, UPPER A-ARM SUSPENSION
-
90403-439 ...AXLE...AXLE
-
108409-075 SCREW, CAPSCREW, CAP
-
110504-942 A-ARM, REAR - LOWER RIGHT - BLACK (INC. FOUR NO. 12 AND TWO NO. 13)A-ARM, REAR - LOWER RIGHT - BLACK (INC. FOUR NO. 12 AND TWO NO. 13)
-
110504-943 A-ARM, REAR - LOWER LEFT - BLACK (INC. FOUR NO. 12 AND TWO NO. 13)A-ARM, REAR - LOWER LEFT - BLACK (INC. FOUR NO. 12 AND TWO NO. 13)
-
120403-409 ...BUSHING...BUSHING
-
130403-438 ...COLLAR...COLLAR
-
140423-334 SCREW, CAPSCREW, CAP
-
152502-350 KIT, HALFSHAFT (INC. 16-19)KIT, HALFSHAFT (INC. 16-19)
-
162436-111 ...REPAIR KIT, BOOT (INC. 17)...REPAIR KIT, BOOT (INC. 17)
-
171441-988 ......CLIP, RETAINING......CLIP, RETAINING
-
181402-884 ...PIN, DETENT...PIN, DETENT
-
191402-890 ...CLIP, RETAINING...CLIP, RETAINING
-
200504-999 KNUCKLE - ASSEMBLY (INC. 21-24)KNUCKLE - ASSEMBLY (INC. 21-24)
-
211402-809 ...BEARING...BEARING
-
220423-423 ...RING, RETAINING...RING, RETAINING
-
230403-437 ...COLLAR, SUSPENSION BUSHING...COLLAR, SUSPENSION BUSHING
-
240403-283 ...BUSHING, SUSPENSION...BUSHING, SUSPENSION
-
258409-000 SCREW, CAPSCREW, CAP
