FRONT SUSPENSION ASSEMBLY для Arctic Cat 90 2X4 UTILITY [A2016KUB2BUSR] - 2016 года выпуска
-
№АртикулНазвание
-
13306-856 SHOCK/SPRING ASSEMBLY - (BLACK)SHOCK/SPRING ASSEMBLY - (BLACK)
-
23307-068 SCREW, CAPSCREW, CAP
-
33303-309 SCREW, CAPSCREW, CAP
-
43307-058 NUTNUT
-
53306-854 ARM, SWING - RIGHT (INC. TWO NO. 6, ONE NO. 7, ONE NO. 8, ONE NO. 9, AND ONE NO. 10)ARM, SWING - RIGHT (INC. TWO NO. 6, ONE NO. 7, ONE NO. 8, ONE NO. 9, AND ONE NO. 10)
-
53306-855 ARM, SWING - LEFT (INC. TWO NO. 6, ONE NO. 7, ONE NO. 8, ONE NO. 9, AND ONE NO. 10)ARM, SWING - LEFT (INC. TWO NO. 6, ONE NO. 7, ONE NO. 8, ONE NO. 9, AND ONE NO. 10)
-
63303-216 ...BUSHING...BUSHING
-
73303-218 ...BUSHING...BUSHING
-
83303-217 ...BUSHING...BUSHING
-
93303-393 ...FITTING, GREASE...FITTING, GREASE
-
103303-394 ...CAP, GREASE FITTING...CAP, GREASE FITTING
-
113303-329 NUT, CASTLENUT, CASTLE
-
123303-337 PIN, COTTERPIN, COTTER
-
133303-219 CAP SWING ARMCAP SWING ARM
-
143303-220 SEAL SWING ARMSEAL SWING ARM
-
153303-178 SHAFT, STEERING - RIGHTSHAFT, STEERING - RIGHT
-
153303-180 SHAFT, STEERING - LEFTSHAFT, STEERING - LEFT
-
163304-595 BOLT, FLANGEBOLT, FLANGE
-
173304-031 U-NUTU-NUT
