WHEEL AND TIRE ASSEMBLY для Arctic Cat HDX 700 XT CAMO [U2016R6T1PUSH] - 2016 года выпуска
-
№АртикулНазвание
-
10423-557 SCREW, SHOULDERSCREW, SHOULDER
-
21436-418 DISC, BRAKE (FRONT) 10 INCHDISC, BRAKE (FRONT) 10 INCH
-
21436-164 DISC, BRAKE (REAR) 8 INCHDISC, BRAKE (REAR) 8 INCH
-
31502-433 HUB - ASSEMBLY (FRONT) (INC. 4)HUB - ASSEMBLY (FRONT) (INC. 4)
-
31502-437 HUB - ASSEMBLY (REAR) (INC. 4)HUB - ASSEMBLY (REAR) (INC. 4)
-
40402-974 ...STUD...STUD
-
50423-407 PIN, COTTERPIN, COTTER
-
60423-607 NUT, CASTLENUT, CASTLE
-
72402-263 WHEEL - FRONT (INC. 8)WHEEL - FRONT (INC. 8)
-
82402-277 CAP, WHEELCAP, WHEEL
-
90402-064 STEM, VALVE - W/CAP (INC. 10)STEM, VALVE - W/CAP (INC. 10)
-
110423-618 NUT, LUG - CHROMENUT, LUG - CHROME
-
121402-953 TIRE - FRONTTIRE - FRONT
-
132402-264 WHEEL - REAR (INC. 8)WHEEL - REAR (INC. 8)
-
141402-954 TIRE - REARTIRE - REAR
