STEERING ASSEMBLY для Arctic Cat TRV 550 XT EPS L7E WHITE [A2016TGO1P7EW] - 2016 года выпуска
-
№АртикулНазвание
-
18408-835 SCREW, CAPSCREW, CAP
-
20405-035 CAP, STEERING ADJUSTERCAP, STEERING ADJUSTER
-
30505-484 CAP, HOUSINGCAP, HOUSING
-
40405-260 BLOCK, MOUNTINGBLOCK, MOUNTING
-
50405-259 BLOCK, MOUNTINGBLOCK, MOUNTING
-
60505-712 POST, STEERINGPOST, STEERING
-
70423-505 SCREW, SHOULDERSCREW, SHOULDER
-
88020-045 SCREW, CAPSCREW, CAP
-
98040-366 NUT, LOCKNUT, LOCK
-
100505-951 ASSEMBLY, ELECTRONIC POWER STEERINGASSEMBLY, ELECTRONIC POWER STEERING
-
118409-020 SCREW, CAPSCREW, CAP
-
120505-664 ARM, STEERINGARM, STEERING
-
138408-816 SCREW, CAPSCREW, CAP
-
140602-233 FLANGE, BEARINGFLANGE, BEARING
-
150405-052 BEARING W/INVERTED OIL SEALBEARING W/INVERTED OIL SEAL
-
160505-872 TIE ROD - ASSEMBLY (INC. 17-23)TIE ROD - ASSEMBLY (INC. 17-23)
-
170505-875 ...END, TIE ROD - LEFT-HAND THREAD - KIT (INC. 18 AND ONE NO. 19-20)...END, TIE ROD - LEFT-HAND THREAD - KIT (INC. 18 AND ONE NO. 19-20)
-
180423-013 ......NUT - LEFT-HAND THREAD......NUT - LEFT-HAND THREAD
-
190623-175 ......PIN, COTTER......PIN, COTTER
-
200423-157 ......NUT......NUT
-
210405-281 ...TIE ROD...TIE ROD
-
220505-874 ...END, TIE ROD - RIGHT-HAND THREAD - KIT (INC. 23 AND ONE NO. 19-20)...END, TIE ROD - RIGHT-HAND THREAD - KIT (INC. 23 AND ONE NO. 19-20)
-
238420-002 ...NUT - RIGHT-HAND THREAD...NUT - RIGHT-HAND THREAD
-
240505-770 LOCK, STEERING - ASSEMBLY (INC. 25-31)LOCK, STEERING - ASSEMBLY (INC. 25-31)
-
250405-409 ...MOUNT, STEERING LOCK...MOUNT, STEERING LOCK
-
261423-112 ...SCREW, CAP...SCREW, CAP
-
278050-247 ...WASHER...WASHER
-
288424-802 ...NUT...NUT
-
290505-710 ...MOUNT, STEERING LOCK...MOUNT, STEERING LOCK
-
301423-059 ...SCREW, MACHINE...SCREW, MACHINE
-
313306-182 ...LOCK, STEERING...LOCK, STEERING
-
322441-251 TOOL, ANTI-TAMPER (OPTIONAL)TOOL, ANTI-TAMPER (OPTIONAL)
