WHEEL AND TIRE ASSEMBLY для Arctic Cat WILDCAT TRAIL LTD WHITE - 2017 года выпуска
-
№АртикулНазвание
-
10423-557 SCREW, SHOULDERSCREW, SHOULDER
-
21436-808 KIT, BRAKE DISCKIT, BRAKE DISC
-
31502-462 HUB, WHEEL (INC. 4)HUB, WHEEL (INC. 4)
-
40402-974 ...STUD...STUD
-
50423-407 PIN, COTTERPIN, COTTER
-
60423-607 NUT, CASTLENUT, CASTLE
-
72402-381 WHEEL - FRONT - GREEN (INC. 8)WHEEL - FRONT - GREEN (INC. 8)
-
82402-197 ...CAP, WHEEL...CAP, WHEEL
-
90402-064 STEM, VALVE - W/CAPSTEM, VALVE - W/CAP
-
101423-260 NUT, LUG - BLACKNUT, LUG - BLACK
-
112402-111 TIRE - FRONT - CARLISLE, TPRO - 25X8R12TIRE - FRONT - CARLISLE, TPRO - 25X8R12
-
122402-382 WHEEL - REAR - GREEN (INC. 8)WHEEL - REAR - GREEN (INC. 8)
-
132402-112 TIRE - REAR - CARLISLE, TPRO - 25X10R12TIRE - REAR - CARLISLE, TPRO - 25X10R12
