WIRING HARNESS ASSEMBLY для Arctic Cat WILDCAT TRAIL RED - 2017 года выпуска
-
№АртикулНазвание
-
10486-586 HARNESS, MAIN (INC. 2-11)HARNESS, MAIN (INC. 2-11)
-
20486-164 ...TETHER, ACCESSORY CONNECTOR...TETHER, ACCESSORY CONNECTOR
-
30430-085 ...COVER, FUSE BLOCK...COVER, FUSE BLOCK
-
40430-037 ...HOLDER, FUSE...HOLDER, FUSE
-
50430-032 ...FUSE - 10 AMP...FUSE - 10 AMP
-
50430-031 ...FUSE - 15 AMP...FUSE - 15 AMP
-
50430-030 ...FUSE - 30 AMP...FUSE - 30 AMP
-
60430-045 ...RELAY (4-PIN) 20 AMP...RELAY (4-PIN) 20 AMP
-
70401-100 ...CIRCUIT BREAKER, MINI - 15 AMP...CIRCUIT BREAKER, MINI - 15 AMP
-
85411-487 ...DECAL, FUSE BLOCK...DECAL, FUSE BLOCK
-
90430-086 ...SEAL...SEAL
-
100430-103 ...COVER, DIAGNOSTICS CONNECTOR...COVER, DIAGNOSTICS CONNECTOR
-
110430-102 ...CLIP, ROUTING...CLIP, ROUTING
-
128476-625 SCREW, CAPSCREW, CAP
-
130824-072 REGULATOR, VOLTAGEREGULATOR, VOLTAGE
-
140623-038 NUT W/WASHERNUT W/WASHER
-
158468-425 SCREW, MACHINESCREW, MACHINE
-
160123-802 WASHERWASHER
-
170409-064 SENSOR, TILTSENSOR, TILT
-
180423-493 NUT W/WASHERNUT W/WASHER
-
194406-315 BRACKET, COILBRACKET, COIL
-
200824-079 COIL, IGNITION - ASSEMBLY (INC. 21)COIL, IGNITION - ASSEMBLY (INC. 21)
-
210824-075 ...CAP, SPARK PLUG...CAP, SPARK PLUG
-
220423-538 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
235506-240 TRAY, ELECTRICAL - BLACKTRAY, ELECTRICAL - BLACK
-
248060-686 RIVETRIVET
-
250745-388 BRACKET MOUNTING- PDMBRACKET MOUNTING- PDM
-
260530-196 ECMECM
-
270423-086 GROMMETGROMMET
-
281423-217 BOLT, SHOULDERBOLT, SHOULDER
-
290123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
300423-075 TIE, CABLE - PUSH MOUNTTIE, CABLE - PUSH MOUNT
