IDLER WHEEL ASSY. для Arctic Cat ZR 900 EFI (Black-Green) - 2004 года выпуска
-
№АртикулНазвание
-
12604-198 WHEEL, IDLER (INC. 2, 3 AND GREEN)WHEEL, IDLER (INC. 2, 3 AND GREEN)
-
21604-847 BEARINGBEARING
-
30623-946 RING, RETAININGRING, RETAINING
-
40623-664 WASHERWASHER
-
58020-232 SCREW, CAPSCREW, CAP
-
61604-187 WASHERWASHER
-
78020-224 SCREW, CAPSCREW, CAP
-
82604-579 BLOCK, MOUNTING, IDLER WHEELBLOCK, MOUNTING, IDLER WHEEL
-
98048-486 NUT, LOCKNUT, LOCK
-
101604-792 AXLEAXLE
-
110623-912 WASHERWASHER
-
121604-793 SPACER, SHOCK ARM (FRONT)SPACER, SHOCK ARM (FRONT)
-
130623-907 SCREW, CAPSCREW, CAP
-
140623-044 WASHERWASHER
-
152604-378 BLOCK, SLIDEBLOCK, SLIDE
-
162604-516 SLIDE, SPRINGSLIDE, SPRING
-
178050-282 WASHERWASHER
-
188002-229 SCREW, CAPSCREW, CAP
-
190603-105 SPACERSPACER
-
201704-016 PIVOT REAR SHOCK (INC. 21, 22)PIVOT REAR SHOCK (INC. 21, 22)
-
211623-010 FITTING, GREASEFITTING, GREASE
-
221623-011 WASHER, GREASE FITTINGWASHER, GREASE FITTING
-
231604-209 AXLEAXLE
-
240623-675 WASHERWASHER
-
250604-459 WHEEL, IDLER (INC. 26, 29)WHEEL, IDLER (INC. 26, 29)
-
260107-598 BEARINGBEARING
-
270123-798 RING, RETAININGRING, RETAINING
-
281604-772 INSERT, WHEEL, INSIDEINSERT, WHEEL, INSIDE
-
291604-773 INSERT, WHEEL, OUTSIDEINSERT, WHEEL, OUTSIDE
-
301604-213 SPACERSPACER
-
311604-837 WHEEL, IDLER (INC. 2, 3)WHEEL, IDLER (INC. 2, 3)
-
328020-226 SCREW, CAPSCREW, CAP
-
330623-123 SCREW, CAPSCREW, CAP
-
348042-486 NUTNUT
-
358051-277 WASHER, LOCKWASHER, LOCK
-
360704-854 SPACERSPACER
-
370604-144 SPACER WHEEL (REAR)SPACER WHEEL (REAR)
-
381604-217 AXLE (REAR)AXLE (REAR)
-
390604-968 BUSHING, SPACERBUSHING, SPACER
-
401604-685 WHEEL, IDLER (INC. 26, 29)WHEEL, IDLER (INC. 26, 29)
-
410604-937 SPACER WHEEL (REAR)SPACER WHEEL (REAR)
-
420623-220 WASHERWASHER
-
430604-936 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
441604-692 WHEEL, IDLER (INC. 26, 27 AND 45)WHEEL, IDLER (INC. 26, 27 AND 45)
-
451604-774 INSERT, WHEELINSERT, WHEEL
-
460123-570 WASHERWASHER
-
478002-223 SCREW, CAPSCREW, CAP
-
480604-246 CAP, IDLER WHEELCAP, IDLER WHEEL
