IDLER WHEEL ASSEMBLY для Arctic Cat PANTHER 660 TRAIL - 2007 года выпуска
-
№АртикулНазвание
-
11604-952 CAP, IDLER WHEELCAP, IDLER WHEEL
-
28020-232 SCREW, CAPSCREW, CAP
-
38050-282 WASHERWASHER
-
43604-043 WHEEL, IDLER - PLATINUM (INC. 5-6)WHEEL, IDLER - PLATINUM (INC. 5-6)
-
50623-946 ...RING, RETAINING...RING, RETAINING
-
63604-033 ...BEARING...BEARING
-
71604-187 WASHERWASHER
-
88020-224 SCREW, CAPSCREW, CAP
-
92604-579 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
108047-486 NUT, LOCKNUT, LOCK
-
111704-272 PIVOT, REAR SHOCK (INC. 12-13)PIVOT, REAR SHOCK (INC. 12-13)
-
121623-010 ...FITTING, GREASE...FITTING, GREASE
-
131623-011 ...WASHER, GREASE FITTING...WASHER, GREASE FITTING
-
141604-329 AXLE, SHOCK PIVOTAXLE, SHOCK PIVOT
-
158020-228 SCREW, CAPSCREW, CAP
-
161623-037 SCREW, CAPSCREW, CAP
-
170623-044 WASHERWASHER
-
182604-737 AXLE, INNERAXLE, INNER
-
191704-235 BRACKET, MOUNTING - FRONT ARM SHOCKBRACKET, MOUNTING - FRONT ARM SHOCK
-
203604-039 WHEEL, IDLER (INC. 5-6)WHEEL, IDLER (INC. 5-6)
-
212604-964 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
228047-490 NUT, LOCKNUT, LOCK
-
232604-378 BLOCK, SLIDEBLOCK, SLIDE
-
242604-516 SLIDE, SPRINGSLIDE, SPRING
-
258050-282 WASHERWASHER
-
268002-229 SCREW, CAPSCREW, CAP
-
272604-283 AXLE, REAR WHEELAXLE, REAR WHEEL
-
280623-921 WASHERWASHER
-
291604-940 SPACER, REAR WHEELSPACER, REAR WHEEL
-
303604-049 WHEEL, IDLER (INC. 5-6)WHEEL, IDLER (INC. 5-6)
-
311704-489 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
328042-486 NUTNUT
-
330623-123 SCREW, CAPSCREW, CAP
-
343604-055 WHEEL, IDLER - PLATINUM (INC. 5-6)WHEEL, IDLER - PLATINUM (INC. 5-6)
-
351623-248 SCREW, CAPSCREW, CAP
-
360623-664 WASHERWASHER
