DRIVEN CLUTCH для Arctic Cat BEARCAT 570 INTERNATIONAL - 2008 года выпуска

-
№АртикулНазвание
-
0726-230 DRIVEN CLUTCH ASSEMBLYDRIVEN CLUTCH ASSEMBLY
-
10648-009 BEARINGBEARING
-
20148-198 WASHER, THRUST: 0.030 IN.WASHER, THRUST: 0.030 IN.
-
20148-199 WASHER, THRUST: 0.060 IN.WASHER, THRUST: 0.060 IN.
-
30648-014 BRACKET, TORQUE - 49?BRACKET, TORQUE - 49?
-
30648-125 BRACKET, TORQUE - 51?/49...(6-9,000 FT ALT.)BRACKET, TORQUE - 51?/49...(6-9,000 FT ALT.)
-
30648-126 BRACKET, TORQUE - 53?/51... (OVER 9,000 FT ALT.)BRACKET, TORQUE - 53?/51... (OVER 9,000 FT ALT.)
-
48051-152 WASHER, LOCKWASHER, LOCK
-
58005-404 SCREW, SOCKET HEADSCREW, SOCKET HEAD
-
60648-114 SPRING, DRIVEN CLUTCH - RED/WHITESPRING, DRIVEN CLUTCH - RED/WHITE
-
60148-227 SPRING, DRIVEN CLUTCH - YELLOW (OVER 6,000 FT ALT.)SPRING, DRIVEN CLUTCH - YELLOW (OVER 6,000 FT ALT.)
-
70748-018 PLATE, ROLLER - ASSEMBLY (INC. ONE NO. 1 AND 8-11)PLATE, ROLLER - ASSEMBLY (INC. ONE NO. 1 AND 8-11)
-
88070-224 ...PIN, SPRING...PIN, SPRING
-
90648-097 ...PIN, CAM ROLLER...PIN, CAM ROLLER
-
100648-082 ...WASHER, THRUST - CAM ROLLER...WASHER, THRUST - CAM ROLLER
-
110648-079 ...ROLLER, CAM...ROLLER, CAM
-
128040-426 NUT, LOCKNUT, LOCK
