GEARCASE ASSEMBLY для Arctic Cat BEARCAT 570 XT - 2009 года выпуска
-
№АртикулНазвание
-
-1702-054 COMPLETE GEARCASE ASSEMBLYCOMPLETE GEARCASE ASSEMBLY
-
11702-064 GEARCASE (INC. 2-3)GEARCASE (INC. 2-3)
-
21602-915 ...PIN, DOWEL...PIN, DOWEL
-
32602-159 ...SEAL, OIL...SEAL, OIL
-
40702-970 FORK, SHIFT - ASSEMBLY (INC. 5-7)FORK, SHIFT - ASSEMBLY (INC. 5-7)
-
52602-013 ...SEAL, OIL...SEAL, OIL
-
62602-124 ...ARM, SHIFT FORK...ARM, SHIFT FORK
-
78468-620 ...SCREW, MACHINE...SCREW, MACHINE
-
82602-127 BLOCK, SLIDERBLOCK, SLIDER
-
90702-910 SLIDER ASSEMBLY (INC. 10-14)SLIDER ASSEMBLY (INC. 10-14)
-
102602-040 ...RING, RETAINING...RING, RETAINING
-
112602-064 ...WASHER, THRUST...WASHER, THRUST
-
142602-063 ...SLIDER...SLIDER
-
150702-853 GEAR, TRANSFER - 66T/34T - ASSEMBLY (INC. 16-22)GEAR, TRANSFER - 66T/34T - ASSEMBLY (INC. 16-22)
-
161602-842 ...BEARING...BEARING
-
172602-058 ...WASHER, SPACER...WASHER, SPACER
-
180702-867 ...GEAR, PLANETARY - ASSEMBLY...GEAR, PLANETARY - ASSEMBLY
-
191602-840 ...BEARING, THRUST...BEARING, THRUST
-
201602-841 ...WASHER, THRUST...WASHER, THRUST
-
210702-852 ...GEAR, TRANSFER (INC. ONE NO. 22)...GEAR, TRANSFER (INC. ONE NO. 22)
-
221602-981 ...... BEARING...... BEARING
-
230702-686 SHAFT, INPUT - 54T (INC. ONE NO. 22)SHAFT, INPUT - 54T (INC. ONE NO. 22)
-
240702-978 COVER, GEARCASE (INC. 25-28)COVER, GEARCASE (INC. 25-28)
-
252602-160 ...SEAL, OIL...SEAL, OIL
-
261602-982 ...BEARING...BEARING
-
272602-099 ...PLUG, DRAIN...PLUG, DRAIN
-
281602-213 ...O-RING...O-RING
-
290423-538 SCREW, MACHINESCREW, MACHINE
-
302602-183 GASKET, GEARCASEGASKET, GEARCASE
-
**4639-628 FLUID, GEARCASE - 12 OZ (NOT ILLUSTRATED)FLUID, GEARCASE - 12 OZ (NOT ILLUSTRATED)
