IDLER WHEEL ASSEMBLY для Arctic Cat BEARCAT 570 XT - 2009 года выпуска
-
№АртикулНазвание
-
11604-952 CAP, IDLER WHEELCAP, IDLER WHEEL
-
28408-880 SCREW, CAPSCREW, CAP
-
38450-133 WASHERWASHER
-
43604-454 WHEEL, IDLER - BLUE (INC. 5-6)WHEEL, IDLER - BLUE (INC. 5-6)
-
53604-033 ...BEARING...BEARING
-
60623-946 ...RING, RETAINING...RING, RETAINING
-
78408-835 SCREW, CAPSCREW, CAP
-
83604-004 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
98427-802 NUT, LOCKNUT, LOCK
-
101623-756 SCREW, CAPSCREW, CAP
-
113604-432 SPACERSPACER
-
123604-420 WHEEL, IDLERWHEEL, IDLER
-
133604-430 SPACERSPACER
-
141704-770 BRACKET, MOUNTING - FRONT SHOCKBRACKET, MOUNTING - FRONT SHOCK
-
153604-429 AXLEAXLE
-
168427-002 NUT, LOCKNUT, LOCK
-
171704-674 PIVOT, SHOCK (INC. 18-19)PIVOT, SHOCK (INC. 18-19)
-
181623-011 ...WASHER...WASHER
-
191623-010 ...FITTING, GREASE...FITTING, GREASE
-
203604-325 SPACERSPACER
-
211704-279 SPRING, OVERLOAD - ASSEMBLY (INC. 22-25)SPRING, OVERLOAD - ASSEMBLY (INC. 22-25)
-
220623-121 ...SCREW, MACHINE...SCREW, MACHINE
-
232604-788 ...BLOCK, WEAR...BLOCK, WEAR
-
248041-276 ...NUT, LOCK...NUT, LOCK
-
251604-412 ...CLIP, RETAINING...CLIP, RETAINING
-
260604-739 BUSHING, OVERLOAD SPRINGBUSHING, OVERLOAD SPRING
-
270623-746 WASHERWASHER
-
281604-430 SPACER, SPRING SLIDESPACER, SPRING SLIDE
-
292604-516 SLIDE, SPRINGSLIDE, SPRING
