MAGNETO для Arctic Cat M8 SNO PRO LE 153 - BLACK [S2010M8HLEOSB] (INTERNATIONAL) - 2010 года выпуска
![](/wa-data/public/shop/sheme/arctic-cat/snow/38693.png)
-
№АртикулНазвание
-
13007-711 STATORSTATOR
-
23007-315 ROTOR/FLYWHEELROTOR/FLYWHEEL
-
33007-546 BASE, STATOR - PLATEBASE, STATOR - PLATE
-
43007-317 SENSOR, IGNITION TIMINGSENSOR, IGNITION TIMING
-
53007-318 SENSOR, IGNITION TIMINGSENSOR, IGNITION TIMING
-
63005-960 PLATE, STATOR LEAD WIREPLATE, STATOR LEAD WIRE
-
73007-433 BOLTBOLT
-
83005-775 GROMMET, STATOR LEAD WIREGROMMET, STATOR LEAD WIRE
-
93006-476 BOLTBOLT
-
103005-987 WASHERWASHER
-
113007-371 BOLTBOLT
-
123007-449 BOLTBOLT
-
133007-450 BOLTBOLT
-
143004-540 KEYKEY
-
153007-547 GROMMETGROMMET
