REAR SUSPENSION FRONT ARM SHOCK ABSORBER для Arctic Cat SNO PRO 600 (INTERNATONAL) - 2012 года выпуска

№

Артикул

Название
-

2704-155 COMPLETE SHOCK ABSORBER

COMPLETE SHOCK ABSORBER

92 760 ₽
1

3604-576 EYELET, SHOCK

EYELET, SHOCK

8 730 ₽
2

3604-525 ROD, SHOCK

ROD, SHOCK

12 890 ₽
3

2603-849 KIT, SEAL/REBUILD (INC. 4-8)

KIT, SEAL/REBUILD (INC. 4-8)

22 870 ₽
4

3604-530 ...BUMPER

...BUMPER

7 270 ₽
5

2604-413 ...BEARING - ASSEMBLY

...BEARING - ASSEMBLY

23 290 ₽
6

2603-994 ...STRAP, PISTON

...STRAP, PISTON

4 150 ₽
7

2604-214 ...O-RING

...O-RING

690 ₽
8

0603-301 ...NUT

...NUT

980 ₽
9

0603-540 WASHER, TOP OUT

WASHER, TOP OUT

2 490 ₽
10

0603-349 VALVE, 1.300 X 0.008 IN.

VALVE, 1.300 X 0.008 IN.

2 070 ₽
11

0603-333 VALVE, 0.800 X 0.006 IN.

VALVE, 0.800 X 0.006 IN.

2 070 ₽
12

0603-337 VALVE, 0.900 X 0.008 IN.

VALVE, 0.900 X 0.008 IN.

1 870 ₽
13

0603-890 VALVE, 1.300 X 0.015 IN.

VALVE, 1.300 X 0.015 IN.

1 040 ₽
14

3604-788 VALVE, RING - 1.250 X 0.012 IN.

VALVE, RING - 1.250 X 0.012 IN.

2 700 ₽
15

0603-343 VALVE, 1.100 X 0.008 IN.

VALVE, 1.100 X 0.008 IN.

1 040 ₽
16

0603-891 VALVE, 1.300 X 0.012 IN.

VALVE, 1.300 X 0.012 IN.

1 870 ₽
17

2603-987 PISTON, HIGH FLOW

PISTON, HIGH FLOW

5 820 ₽
18

3604-171 VALVE, 0.600 X 0.004 IN.

VALVE, 0.600 X 0.004 IN.

1 870 ₽
19

0603-731 VALVE, 0.700 X 0.004 IN.

VALVE, 0.700 X 0.004 IN.

2 070 ₽
20

0603-895 VALVE, 0.800 X 0.004 IN.

VALVE, 0.800 X 0.004 IN.

1 000 ₽
21

3604-729 BODY, SHOCK

BODY, SHOCK

27 450 ₽
22

2604-840 NUT, ADJUSTER

NUT, ADJUSTER

7 480 ₽
23

2604-841 COLLAR, LOCKING - ADJUSTER NUT

COLLAR, LOCKING - ADJUSTER NUT

7 480 ₽
24

3604-522 END CAP, SHOCK/RESERVOIR (INC. 25-27)

END CAP, SHOCK/RESERVOIR (INC. 25-27)

60 940 ₽
25

3604-532 ...CLAMP, BODY/END CAP

...CLAMP, BODY/END CAP

12 470 ₽
26

3604-526 ...BEARING

...BEARING

13 310 ₽
27

3604-527 ...RING, RETAINING

...RING, RETAINING

2 070 ₽
28

3604-539 KIT, REBUILD - RESERVOIR (INC. 29-33 AND 39-41)

KIT, REBUILD - RESERVOIR (INC. 29-33 AND 39-41)

29 950 ₽
29

1603-235 ...STRAP, PISTON

...STRAP, PISTON

3 110 ₽
30

1604-316 ...SCREW, MACHINE W/O-RING (INC. 31)

...SCREW, MACHINE W/O-RING (INC. 31)

770 ₽
31

1604-425 ......O-RING

......O-RING

690 ₽
32

2603-502 ...O-RING

...O-RING

980 ₽
33

0603-671 ...O-RING

...O-RING

630 ₽
34

3604-528 RESERVOIR

RESERVOIR

27 450 ₽
35

3604-724 DECAL, RESERVOIR

DECAL, RESERVOIR

1 450 ₽
36

3604-524 PISTON, INTERNAL FLOATING

PISTON, INTERNAL FLOATING

17 470 ₽
37

0604-992 RING, RETAINING

RING, RETAINING

920 ₽
38

2603-525 END CAP, RESERVOIR (INC. 33 AND 39-40)

END CAP, RESERVOIR (INC. 33 AND 39-40)

11 850 ₽
39

0703-341 ...VALVE, PRESSURE - ASSEMBLY (INC. 40)

...VALVE, PRESSURE - ASSEMBLY (INC. 40)

8 310 ₽
40

1604-318 ......O-RING

......O-RING

1 870 ₽
41

0624-097 SCREW, VALVE

SCREW, VALVE

130 ₽
42

3604-187 PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 43-45)

PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 43-45)

41 590 ₽
43

0603-331 ...VALVE, 0.700 X 0.008 IN.

...VALVE, 0.700 X 0.008 IN.

920 ₽
44

2603-501 ...VALVE, 0.700 X 0.010 IN.

...VALVE, 0.700 X 0.010 IN.

2 070 ₽
45

3604-165 ...PLATE, BACKUP

...PLATE, BACKUP

2 070 ₽
46

2603-527 CARTRIDGE, DAMPING ADJUSTER (INC. 32)

CARTRIDGE, DAMPING ADJUSTER (INC. 32)

14 140 ₽
47

5639-240 OIL, SHOCK - 1 QT

OIL, SHOCK - 1 QT

3 950 ₽
