FRONT SEAT ASSEMBLY для Arctic Cat TZ1 - 2012 года выпуска
-
№АртикулНазвание
-
14706-910 SEAT ASSEMBLY - FRONT (INC. 2-20)SEAT ASSEMBLY - FRONT (INC. 2-20)
-
24706-906 ...COVER, SEAT (INC. 3)...COVER, SEAT (INC. 3)
-
35606-378 ......WIRE, SEAT......WIRE, SEAT
-
43706-737 ...FOAM, SEAT...FOAM, SEAT
-
50609-869 ...PAD, SEAT HEATER...PAD, SEAT HEATER
-
60624-528 ...STAPLE...STAPLE
-
75606-379 ...WIRE, SEAT...WIRE, SEAT
-
85606-086 ...LEVER, HANDHOLD...LEVER, HANDHOLD
-
91623-715 ...CLIP, ANTI-ROTATIONAL...CLIP, ANTI-ROTATIONAL
-
100423-396 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
114706-360 ...PANEL, SEAT-BASE...PANEL, SEAT-BASE
-
120406-879 ...BUMPER, SEAT...BUMPER, SEAT
-
133706-895 ...PLATE, CLAMP...PLATE, CLAMP
-
145606-095 ...SPRING, ADJUSTMENT...SPRING, ADJUSTMENT
-
153706-892 ...GUSSET, SEAT...GUSSET, SEAT
-
164606-301 ...BASE, SEAT...BASE, SEAT
-
178427-602 ...NUT, LOCK...NUT, LOCK
-
188061-688 ...RIVET,BLIND-LF SS66 ZINC...RIVET,BLIND-LF SS66 ZINC
-
193706-931 ...FRAME, SEAT...FRAME, SEAT
-
208468-645 ...SCREW, MACHINE...SCREW, MACHINE
-
218408-516 SCREW, CAPSCREW, CAP
