HYDRAULIC BRAKE CONTROL ASSEMBLY для Arctic Cat XF 800 SNO PRO - ANNIVERSARY EDITION - 2012 года выпуска
-
№АртикулНазвание
-
12602-344 BRAKE ASSEMBLY (INC. 2-14)BRAKE ASSEMBLY (INC. 2-14)
-
22602-426 ...PISTON ASSEMBLY...PISTON ASSEMBLY
-
32602-427 ...LEVER, BRAKE - ASSEMBLY (INC. 4-5)...LEVER, BRAKE - ASSEMBLY (INC. 4-5)
-
42602-428 ......LOCK, BRAKE LEVER - KIT......LOCK, BRAKE LEVER - KIT
-
52602-431 ......SCREW, SHOULDER......SCREW, SHOULDER
-
61602-936 ...SCREW, MACHINE...SCREW, MACHINE
-
70502-869 ...CLAMP, HANDLEBAR...CLAMP, HANDLEBAR
-
82602-433 ...RESERVOIR (INC. 9-10)...RESERVOIR (INC. 9-10)
-
92602-518 ......O-RING......O-RING
-
102602-519 ......SCREW, SELF-TAPPING......SCREW, SELF-TAPPING
-
112602-429 ...COVER, RESERVOIR (INC. 12)...COVER, RESERVOIR (INC. 12)
-
122602-520 ......GASKET......GASKET
-
132602-430 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
142602-432 ...SWITCH, BRAKE...SWITCH, BRAKE
-
150423-413 BOLT, BANJO-FITTINGBOLT, BANJO-FITTING
-
162602-424 BRAKELINE, HYDRAULICBRAKELINE, HYDRAULIC
-
170423-178 WASHER, CRUSHWASHER, CRUSH
-
180436-902 FLUID, BRAKE - 12 OZFLUID, BRAKE - 12 OZ
