DRIVE CLUTCH для Arctic Cat F5 [S2014F5CEFUSG] - 2014 года выпуска

№

Артикул

Название
1

0746-435 CLUTCH, DRIVE - UNCALIBRATED (INC. 2-3)

CLUTCH, DRIVE - UNCALIBRATED (INC. 2-3)

108 990 ₽
2

0646-431 ...SCREW, SHOULDER

...SCREW, SHOULDER

290 ₽
3

0646-430 ...WASHER, LOCK

...WASHER, LOCK

40 ₽
4

0646-432 SPRING,CLUTCH - STRIPE-74/228 LB - BLACK/RED

SPRING,CLUTCH - STRIPE-74/228 LB - BLACK/RED

7 900 ₽
5

4639-674 KIT, CAM ARM (INC. 6-9)

KIT, CAM ARM (INC. 6-9)

8 730 ₽
6

8048-366 ...NUT, LOCK

...NUT, LOCK

110 ₽
7

1602-692 ...O-RING

...O-RING

110 ₽
8

1623-183 ...SCREW, SET-CUP PT W/THD LOC-8-32X3/16

...SCREW, SET-CUP PT W/THD LOC-8-32X3/16

250 ₽
9

0646-747 ...PIN, CAM ARM

...PIN, CAM ARM

2 700 ₽
10

0746-702 ARM, CAM-WIDE-P1-58.0 GRAM W/SET SCREW (INC. 8)

ARM, CAM-WIDE-P1-58.0 GRAM W/SET SCREW (INC. 8)

2 070 ₽
10

0746-663 ARM, CAM-WIDE-P2-52 GRAM W/SET SCREW (INC. 8) - 5-9,000 FT ALT.

ARM, CAM-WIDE-P2-52 GRAM W/SET SCREW (INC. 8) - 5-9,000 FT ALT.

1 660 ₽
10

0746-792 ARM, CAM-WIDE-P2-47 GRAM W/SET SCREW (INC. 8) - OVER 9,000 FT ALT.

ARM, CAM-WIDE-P2-47 GRAM W/SET SCREW (INC. 8) - OVER 9,000 FT ALT.

2 070 ₽
