REAR SUSPENSION REAR ARM SHOCK ABSORBER для Arctic Cat ZR 6000 Sno Pro RR - GREEN - INTERNATIONAL [S2014ZRDRROSG] - 2014 года выпуска
-
№АртикулНазвание
-
-2704-488 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
13604-727 EYELET, SHOCK - ASSEMBLY (INC. 2-5)EYELET, SHOCK - ASSEMBLY (INC. 2-5)
-
23604-527 ...RING, RETAINING...RING, RETAINING
-
33604-526 ...BEARING...BEARING
-
41604-315 ...BALL, BLEED...BALL, BLEED
-
52603-529 ...SPRING...SPRING
-
63604-728 SHAFT, SHOCKSHAFT, SHOCK
-
73604-800 ROD, DAMPING ADJUSTER - ASSEMBLYROD, DAMPING ADJUSTER - ASSEMBLY
-
82604-953 NEEDLE, DAMPING W/O-RINGNEEDLE, DAMPING W/O-RING
-
93604-423 VALVE, CHECK - ASSEMBLYVALVE, CHECK - ASSEMBLY
-
102603-013 KIT, REBUILD - SHOCK (INC. 11-18)KIT, REBUILD - SHOCK (INC. 11-18)
-
112604-530 ...SCREW, MACHINE (INC. ONE NO. 12)...SCREW, MACHINE (INC. ONE NO. 12)
-
121604-425 ......O-RING......O-RING
-
132604-956 ...BEARING - ASSEMBLY (INC. ONE NO. 14)...BEARING - ASSEMBLY (INC. ONE NO. 14)
-
140603-671 ......O-RING......O-RING
-
152603-328 ...O-RING...O-RING
-
163604-723 ...STRAP, PISTON...STRAP, PISTON
-
173604-725 ...O-RING...O-RING
-
182604-448 ...NUT...NUT
-
193604-799 BODY, SHOCKBODY, SHOCK
-
202604-449 WASHER, TOP OUTWASHER, TOP OUT
-
213604-628 VALVE, 0.800 X 0.004 IN.VALVE, 0.800 X 0.004 IN.
-
222604-480 VALVE, 0.950 X 0.010 IN.VALVE, 0.950 X 0.010 IN.
-
232604-485 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
242604-492 VALVE, 1.350 X 0.010 IN.VALVE, 1.350 X 0.010 IN.
-
252604-496 VALVE, 1.425 X 0.008 IN.VALVE, 1.425 X 0.008 IN.
-
262604-502 VALVE, 1.600 X 0.010 IN.VALVE, 1.600 X 0.010 IN.
-
272604-501 VALVE, 1.600 X 0.008 IN.VALVE, 1.600 X 0.008 IN.
-
282604-503 VALVE, 1.600 X 0.012 IN.VALVE, 1.600 X 0.012 IN.
-
292604-692 VALVE, RING - 1.600 X 0.012 IN.VALVE, RING - 1.600 X 0.012 IN.
-
302604-495 VALVE, 1.425 X 0.006 IN.VALVE, 1.425 X 0.006 IN.
-
313604-897 PISTON, 0.039 IN. - ORIFICEPISTON, 0.039 IN. - ORIFICE
-
322604-498 VALVE, 1.425 X 0.012 IN.VALVE, 1.425 X 0.012 IN.
-
333604-626 VALVE, 1.000 X 0.004 IN.VALVE, 1.000 X 0.004 IN.
-
343604-624 WASHER, TOP OUTWASHER, TOP OUT
-
353604-184 WASHER, BACKUPWASHER, BACKUP
-
363604-726 END CAP, BODY/RESERVOIR (INC. 15 AND 37)END CAP, BODY/RESERVOIR (INC. 15 AND 37)
-
372603-504 ...O-RING...O-RING
-
382603-525 END CAP, RESERVOIR (INC. ONE NO. 14 AND 39-40)END CAP, RESERVOIR (INC. ONE NO. 14 AND 39-40)
-
390703-341 ...VALVE, PRESSURE - ASSEMBLY (INC. 40)...VALVE, PRESSURE - ASSEMBLY (INC. 40)
-
401604-318 ......O-RING......O-RING
-
410624-097 SCREW, MACHINESCREW, MACHINE
-
420604-992 RING, RETAININGRING, RETAINING
-
433604-539 KIT, REBUILD - RESERVOIR (INC. ONE NO. 12, 14, 37, AND 44-46)KIT, REBUILD - RESERVOIR (INC. ONE NO. 12, 14, 37, AND 44-46)
-
441604-316 ...SCREW, MACHINE W/O-RING (INC. ONE NO. 12)...SCREW, MACHINE W/O-RING (INC. ONE NO. 12)
-
451603-235 ...STRAP, PISTON...STRAP, PISTON
-
462603-502 ...O-RING...O-RING
-
473604-524 PISTON, INTERNAL FLOATINGPISTON, INTERNAL FLOATING
-
482603-515 RESERVOIRRESERVOIR
-
493604-724 DECAL, RESERVOIRDECAL, RESERVOIR
-
503604-187 PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 51-53)PISTON, CONCENTRIC - DAMPING ADJUSTER (INC. 51-53)
-
510603-331 ...VALVE, 0.700 X 0.008 IN....VALVE, 0.700 X 0.008 IN.
-
522603-501 ...VALVE, 0.700 X 0.010 IN....VALVE, 0.700 X 0.010 IN.
-
533604-165 ...PLATE, BACKUP...PLATE, BACKUP
-
543604-896 CARTRIDGE, DAMPING ADJUSTER (INC. 46)CARTRIDGE, DAMPING ADJUSTER (INC. 46)
-
555639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
