IDLER WHEEL ASSEMBLY для Arctic Cat ZR 8000 Sno Pro RR - GREEN - INTERNTIONAL [S2014ZRHRROSG] - 2014 года выпуска
-
№АртикулНазвание
-
18408-880 SCREW, CAPSCREW, CAP
-
28450-133 WASHERWASHER
-
33604-807 WHEEL, IDLER (INC. 4-5)WHEEL, IDLER (INC. 4-5)
-
43604-033 ...BEARING...BEARING
-
50623-946 ...RING, RETAINING...RING, RETAINING
-
68408-830 SCREW, CAPSCREW, CAP
-
73604-004 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
88427-802 NUT, LOCKNUT, LOCK
-
91423-064 SCREW, CAPSCREW, CAP
-
103604-083 SPACERSPACER
-
110623-912 WASHERWASHER
-
123604-798 AXLE, STEEL-22.2 X 222.2AXLE, STEEL-22.2 X 222.2
-
133604-269 AXLE, ALUM-22.2 X 222.2AXLE, ALUM-22.2 X 222.2
-
141623-992 WASHER, INTERNAL TOOTH LOCKWASHER, INTERNAL TOOTH LOCK
-
158422-002 NUT, LOCKNUT, LOCK
-
162704-208 PIVOT, SHOCK (INC. 17-18)PIVOT, SHOCK (INC. 17-18)
-
179916-963 ...FITTING, GREASE...FITTING, GREASE
-
180104-386 ...BUSHING, FLARED...BUSHING, FLARED
-
192604-698 O-RINGO-RING
-
203604-581 SPACERSPACER
-
213604-204 BLOCK, SLIDEBLOCK, SLIDE
-
222604-515 SLIDE, SPRINGSLIDE, SPRING
-
238408-850 SCREW, CAPSCREW, CAP
-
248408-031 SCREW, CAPSCREW, CAP
-
251623-931 WASHERWASHER
-
263604-641 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
278427-602 NUT, LOCKNUT, LOCK
-
283604-643 WHEEL, IDLERWHEEL, IDLER
-
293604-640 AXLE, REARAXLE, REAR
-
308408-620 SCREW, CAPSCREW, CAP
-
313604-647 ADJUSTER, TRACKADJUSTER, TRACK
-
328422-802 NUT, LOCKNUT, LOCK
-
331623-682 SCREW, CAPSCREW, CAP
