WATER HOSE ASSEMBLY для Arctic Cat BEARCAT 5000 XT GS (ORANGE) [S2015BCNWGUSO] - 2015 года выпуска

-
№АртикулНазвание
-
13007-182 THERMOSTATTHERMOSTAT
-
23003-924 CAP, THERMOSTAT (U.S.)CAP, THERMOSTAT (U.S.)
-
33007-369 BOLT,CYLINDER HEAD COVER NO. 1BOLT,CYLINDER HEAD COVER NO. 1
-
43007-513 HOSE, INLETHOSE, INLET
-
53007-184 HOSE, BYPASS - NO. 1HOSE, BYPASS - NO. 1
-
63007-514 HOSE, BYPASS - NO. 2HOSE, BYPASS - NO. 2
-
73007-186 HOSE, BYPASS - NO. 3HOSE, BYPASS - NO. 3
-
83007-187 FITTING, HOSEFITTING, HOSE
-
93007-188 CLAMP, HOSE - NO. 1CLAMP, HOSE - NO. 1
-
103007-189 CLIP,WATER BYPASS HOSE NO.3CLIP,WATER BYPASS HOSE NO.3
-
113008-488 CLIP (ID:17.8)CLIP (ID:17.8)
-
123007-857 CLAMP, HOSECLAMP, HOSE
-
133007-190 FITTING, HOSEFITTING, HOSE
-
140830-173 O-RINGO-RING
-
153007-515 BOLT,WATER INLET CONNECTORBOLT,WATER INLET CONNECTOR
-
163007-516 CLIP, RETAININGCLIP, RETAINING
