GEARCASE ASSEMBLY для Arctic Cat LYNX 2000 (GREEN) [S2015LXDFCUSG] - 2015 года выпуска
-
№АртикулНазвание
-
-1702-093 GEARCASE ASSEMBLYGEARCASE ASSEMBLY
-
10702-994 HOUSING, GEARCASE (INC. 2-3 AND ONE NO. 4)HOUSING, GEARCASE (INC. 2-3 AND ONE NO. 4)
-
21602-915 ...PIN, DOWEL...PIN, DOWEL
-
32602-159 ...SEAL,OIL-PRE LUBE-50 X 65 X 8MM...SEAL,OIL-PRE LUBE-50 X 65 X 8MM
-
42602-151 ...RING, RETAINING...RING, RETAINING
-
51702-012 GEAR, RING-76T W/BRG (INC. 6)GEAR, RING-76T W/BRG (INC. 6)
-
61602-980 ......BEARING,50MMX72MMX20MM-PEER......BEARING,50MMX72MMX20MM-PEER
-
71702-013 GEAR, PLANETARY - ASSEMBLY (INC. 8-9)GEAR, PLANETARY - ASSEMBLY (INC. 8-9)
-
81602-349 ...GEAR, PLANETARY...GEAR, PLANETARY
-
92602-257 ...RING, RETAINING...RING, RETAINING
-
100702-688 SHAFT, INPUT - 57T (INC. ONE NO. 11)SHAFT, INPUT - 57T (INC. ONE NO. 11)
-
111602-981 ...BEARING...BEARING
-
121702-106 GEAR,TRANSFER-63T/34T-FWD-SPLINED-ASSY (INC. ONE NO. 11 AND 13-14)GEAR,TRANSFER-63T/34T-FWD-SPLINED-ASSY (INC. ONE NO. 11 AND 13-14)
-
132602-259 ...SPACER...SPACER
-
142602-108 ...BEARING,TRANSFER GEAR-17MM- PEER...BEARING,TRANSFER GEAR-17MM- PEER
-
152602-184 GASKET, GEARCASEGASKET, GEARCASE
-
160702-996 COVER, GEARCASE (INC. 17-20)COVER, GEARCASE (INC. 17-20)
-
172602-160 ...SEAL,OIL-PRE LUBE-2.099 X 1.311 X .315...SEAL,OIL-PRE LUBE-2.099 X 1.311 X .315
-
181602-982 ...BEARING...BEARING
-
191602-213 ...O-RING...O-RING
-
202602-099 ...PLUG, FILL-12 MM...PLUG, FILL-12 MM
-
210423-538 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
-5639-219 FLUID, GEARCASE - 15 OZ (NOT ILLUSTRATED)FLUID, GEARCASE - 15 OZ (NOT ILLUSTRATED)
