SUSPENSION FRONT - SHOCK ABSORBER для Arctic Cat M 8000 153 (INTERNATIONAL) (GREEN) [S2015M8HE3OSG] - 2015 года выпуска
-
№АртикулНазвание
-
-3703-468 SHOCK, SKI 436.27MMSHOCK, SKI 436.27MM
-
12603-020 EYELET, SHOCKEYELET, SHOCK
-
23604-809 ROD, SHOCKROD, SHOCK
-
33604-740 BUMPER, SHOCKBUMPER, SHOCK
-
44604-126 BEARING - ASSEMBLYBEARING - ASSEMBLY
-
54604-121 KIT, SEAL/REBUILDKIT, SEAL/REBUILD
-
63604-789 WASHER.TOP OUT-29.5 OD X 9.60 ID X 2 THKWASHER.TOP OUT-29.5 OD X 9.60 ID X 2 THK
-
73603-096 VALVE, 0.700 X 0.012 IN.VALVE, 0.700 X 0.012 IN.
-
83603-104 VALVE, 0.800 X 0.008 IN.VALVE, 0.800 X 0.008 IN.
-
93603-114 VALVE, 0.900 X 0.008 IN.VALVE, 0.900 X 0.008 IN.
-
103603-144 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
113603-174 VALVE, 1.250 X 0.008 IN.VALVE, 1.250 X 0.008 IN.
-
123603-105 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
133603-124 VALVE, 1.000 X 0.008 IN.VALVE, 1.000 X 0.008 IN.
-
143603-182 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
152603-996 PISTON, 0.081 IN. - ORIFICEPISTON, 0.081 IN. - ORIFICE
-
163603-125 VALVE, 1.000 X 0.010 IN.VALVE, 1.000 X 0.010 IN.
-
173603-115 VALVE, 0.900 X 0.010 IN.VALVE, 0.900 X 0.010 IN.
-
183603-102 VALVE, 0.800 X 0.006 IN.VALVE, 0.800 X 0.006 IN.
-
193604-775 WASHER, BACKUPWASHER, BACKUP
-
203604-739 NUT, HEX - 3/8"-24UNFNUT, HEX - 3/8"-24UNF
-
213604-772 PISTON.FLOAT-ASSEMBLYPISTON.FLOAT-ASSEMBLY
-
223604-773 SLEEVE, WEARSLEEVE, WEAR
-
232603-014 NUT, ADJUSTER RING,PRELOAD LOCK-SHOULDEREDNUT, ADJUSTER RING,PRELOAD LOCK-SHOULDERED
-
243604-779 COLLAR, LOCKING - ADJUSTER NUTCOLLAR, LOCKING - ADJUSTER NUT
-
253604-808 BODY, SHOCKBODY, SHOCK
-
261621-728 DECAL, WARNING - HIGH PRESSUREDECAL, WARNING - HIGH PRESSURE
-
272704-257 END CAP, SHOCK - ASSEMBLY (INC. 28-29)END CAP, SHOCK - ASSEMBLY (INC. 28-29)
-
283604-751 ...VALVE, PRESSURE (INC. 29)...VALVE, PRESSURE (INC. 29)
-
293604-733 ......O-RING, VALVE......O-RING, VALVE
-
303604-750 SCREW.MACH-#8-32 X 5MM-SSSCREW.MACH-#8-32 X 5MM-SS
-
315639-530 SEMI-SYN SHOCK OIL-1 QUARTSEMI-SYN SHOCK OIL-1 QUART
