FUEL PUMP ASSEMBLY для Arctic Cat M 8000 HCR 153 (INTERNATIONAL) (GREEN) [S2015M8HHCOSG] - 2015 года выпуска
-
№АртикулНазвание
-
10423-898 SCREW,TSPH-THRD FORM M5X0.8X20MM SEMSSCREW,TSPH-THRD FORM M5X0.8X20MM SEMS
-
22670-042 MOUNT,FUEL PUMPMOUNT,FUEL PUMP
-
32670-472 PUMP,FUEL-2 STRK S/P (INC. 4)PUMP,FUEL-2 STRK S/P (INC. 4)
-
42670-235 ...FLOAT,FUEL PUMP-WALBRO 75-22...FLOAT,FUEL PUMP-WALBRO 75-22
-
50470-838 SEAL,FUEL-PUMPSEAL,FUEL-PUMP
-
62670-377 PICKUP, FUEL - 3MPPICKUP, FUEL - 3MP
-
70610-563 CLAMP, HOSE-13.2MM-15.7MMCLAMP, HOSE-13.2MM-15.7MM
-
82670-442 HOSE, FUEL PUMP/PICKUPHOSE, FUEL PUMP/PICKUP
-
91670-878 FITTING, QUICK-CONNECTFITTING, QUICK-CONNECT
-
100610-971 HOSE, FUEL - IN TANK - 10 FTHOSE, FUEL - IN TANK - 10 FT
-
110623-373 CLAMP, HOSECLAMP, HOSE
-
120123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
120123-903 TIE, CABLE - 11.5 IN.TIE, CABLE - 11.5 IN.
