SUSPENSION FRONT - SHOCK ABSORBER для Arctic Cat M 8000 HCR 153 (INTERNATIONAL) (GREEN) [S2015M8HHCOSG] - 2015 года выпуска
-
№АртикулНазвание
-
-3703-378 SHOCK ABSORBERSHOCK ABSORBER
-
14604-066 KIT, SEAL/BEARING REBUILDKIT, SEAL/BEARING REBUILD
-
23603-415 END CAP, SHOCKEND CAP, SHOCK
-
32603-511 VALVE,AIR-LOW TEMP (FOX)VALVE,AIR-LOW TEMP (FOX)
-
42603-965 SEAL,CAP-EVOL AIR VALVE-.296"ODX.125"IDSEAL,CAP-EVOL AIR VALVE-.296"ODX.125"ID
-
53603-367 CAP, AIR VALVECAP, AIR VALVE
-
63603-371 PISTON, INTERNAL FLOATINGPISTON, INTERNAL FLOATING
-
73603-002 RESERVOIR,EVOL CHAMBER-4.50"RESERVOIR,EVOL CHAMBER-4.50"
-
83603-372 END CAP, RESERVOIREND CAP, RESERVOIR
-
94604-064 DECAL, RESERVOIRDECAL, RESERVOIR
-
103603-301 BODY, SHOCK - UPPERBODY, SHOCK - UPPER
-
113603-376 BEARING,INTERNAL-1.662 ID X .375 TLGBEARING,INTERNAL-1.662 ID X .375 TLG
-
124604-065 DECAL, SHOCKDECAL, SHOCK
-
133603-365 DECAL, "PERFORMANCE SERIES"DECAL, "PERFORMANCE SERIES"
-
143603-291 BEARING - ASSEMBLYBEARING - ASSEMBLY
-
153603-375 ROD, SHOCKROD, SHOCK
-
163603-417 GUIDE, SPRING - ASSEMBLYGUIDE, SPRING - ASSEMBLY
-
170603-540 WASHER, TOP OUT-1.125OD X .378 ID X.093WASHER, TOP OUT-1.125OD X .378 ID X.093
-
180603-334 VALVE, .800X.008 (3/8ID)VALVE, .800X.008 (3/8ID)
-
190603-337 VALVE, 0.900 X 0.008 IN.VALVE, 0.900 X 0.008 IN.
-
200603-340 VALVE, 1.000 X 0.008 IN.VALVE, 1.000 X 0.008 IN.
-
210603-343 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
220603-346 VALVE, 1.250 X 0.008 (3/8 ID)VALVE, 1.250 X 0.008 (3/8 ID)
-
230603-349 VALVE, 1.300 X 0.008 IN.VALVE, 1.300 X 0.008 IN.
-
240603-335 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
250603-348 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
263603-344 VALVE, 1.300 X 0.008 IN.VALVE, 1.300 X 0.008 IN.
-
273603-397 PISTON, 3-PORTPISTON, 3-PORT
-
280603-895 VALVE, 0.800 X 0.004 IN.VALVE, 0.800 X 0.004 IN.
-
290603-882 VALVE, 1.100 X 0.012 IN.VALVE, 1.100 X 0.012 IN.
-
300603-881 VALVE, 1.000 X 0.012 IN.VALVE, 1.000 X 0.012 IN.
-
310603-880 VALVE, 0.900 X 0.012 IN.VALVE, 0.900 X 0.012 IN.
-
322604-966 WASHER, TOP OUTWASHER, TOP OUT
-
333603-023 PISTON, FLOATING W/O-RINGPISTON, FLOATING W/O-RING
-
343603-299 BODY, SHOCK - LOWERBODY, SHOCK - LOWER
-
353603-414 END CAP, SHOCKEND CAP, SHOCK
-
362603-338 SCREW,SET-3/8-24 X .25"SCREW,SET-3/8-24 X .25"
-
374639-012 FLOAT FLUID,FOX RACING SHOCK - 8 OZFLOAT FLUID,FOX RACING SHOCK - 8 OZ
-
385639-530 SEMI-SYN SHOCK OIL-1 QUARTSEMI-SYN SHOCK OIL-1 QUART
